Tiansu Injection Molding Machine

High - Performance Clamping Unit

Tiansu injection molding machine features a clamping unit designed to deliver excellence. The design combines kinematic and dynamic optimization to incorporate a five - point double toggle clamping mechanism arranged at an angle. A hollow spherical head plate and a box-type support plate constitute an innovative template analyzed by finite element method which combines with the template monolithically to achieve high rigidity and reliability. The design results in smooth mold operation with reliable clamping force. The expanded inner gap between tie rods permits the installation of larger molds. The system delivers triple safety interlock protection (mechanical, hydraulic and electrical) to protect operators and provides multi-stage control for mold opening and closing pressure and position along with speed regulation and a low-pressure mold protection device, plus multiple hydraulic ejection modes to fit different requirements.

Precise Injection Unit

The injection unit provides stable and accurate injection through its double - cylinder balanced injection system along with double - guide linear rail support. The equipment features an extensive screw library where screws and barrels undergo specialized treatments such as nitriding and hard chromium plating and are made bimetallic to meet various plastic processing needs. The screw pre - plasticization receives direct drive from a high - performance low - speed high - torque hydraulic motor to maintain stable pre - plasticization quality. High - precision electronic rulers detect positions and permit flexible control over injection speed, pressure, holding pressure as well as holding pressure switching point control through multiple methods.

Energy - Saving Hydraulic Unit

The servo-controlled precision energy-saving power system in the hydraulic unit adjusts power output based on load requirements while reducing electricity consumption by 20% to 80% compared to traditional injection molding machines. Through the use of European-style hydraulic hoses and DIN-standard spherical joints along with G-threaded sealing plugs on valve plates the machine achieves low noise operation and low energy consumption while preventing oil pollution. The maintenance process becomes straightforward due to the detachable oil tank which remains visible and operates together with a self-sealing magnetic oil suction filter and a logical pipe joint design.

Safe and Stable Electrical Control Unit

The device provides IO short - circuit self - protection while holding full CE certification to deliver dependable hardware performance which decreases maintenance expenses together with after - sales costs. The advanced control software facilitates seamless machine operation while enabling automatic calibration and mold parameter acquisition together with enhanced temperature PID control. The operation interface provides user-friendly features that make it straightforward for operators to access.

These are the products our company takes great pride in producing: injection mold, servo hydraulic injection molding machine, injection molding machine mold, pu injection machine, custom injection molders, injection molding equipment, pvc mold, hydraulic molding machine.
