5KW High Quality Off Gird Pure Sine Wave Charger Hybrid Solar Inverter Power Inverter1

Model: MPPT

0.3-1KW

1.5-6KW

Power rating(w)

300W

700W

1500W

3000W

5000W

500W

1000W

2000W

4000W

6000W

Battery

Rated voltage(VDC)

12/24VDC

12/24/48

24/48

48

Charge Current

10A Max

30A Max

Battery Type

Can be set

Input

Voltage Range

85-138VAC/170-275VAC

Frequency

45-65Hz

Output

Voltage Range

110VAC/220VAC; ±5%( Inverter mode)

frequency

50/60Hz±1%( Inverter mode)

Output wave

Pure Sine Wave

Change time

<10ms(Typical load)

Efficiency

>85%(80% Resistive load)

Overload

110-120%/30S;>160%/300ms;

Protection function

Battery over-voltage and low-voltage protection,

overload protection, shor circuit,over-temperature

protection,

MPPT

Solar

Controller

MPPT Voltage Range

12VDC:15V~150VDC;24VDC:30V~150VDC;48V

DC:60V~150VDC

PV Power

12VDC-30A (400W);

24VDC-30A(800W)

12VDC-60A (800W);

24VDC-60A(1600W);

48VDC-60A(3200W)

Rated charge current

30A(Max)

60A(Max)

MPPT efficiency

>99%

Average charging

voltage(lead acid battery

12V/14.2VDC;24V/28.4VDC;48V/56.8VDC

Floating charge voltage

12V/13.75VDC;24V/27.5VDC;48V/55VDC

Operating ambient temperature

-15 ~ +50℃

Storage ambient temperature

-20 - +50℃

Operating / storage environment

0-90% No Condensation

Dimensions:W * D * H (mm)

420*320*122

520*420*222

Packing size: W * D * H (mm)

535*435*172

635*535*252
