TEN 2 Refrigeration Expansion Valve
7 day ago
Danfoss Type TEN 2 Thermostatic Expansion Valve 068Z3385
Product introduction
The TEN2 068Z3385 is a Danfoss type internal equalizer thermostatic expansion valve. R134a refrigerant liquid is injected into the evaporator, and the injection is controlled by the refrigerant superheat. During normal operation, it can prevent excessive motor evaporation pressure, so it is especially suitable for ''dry'' evaporators. In addition, we can also provide valves for different refrigerants.
Brass valve body
The body of TEN2 is made of solid brass and the connection method is flare, which makes the valve installation more stable and not easy to be damaged during operation.
Stainless Steel Material
It is made from stainless steel for extreme durability and also has interchangeable hole components for quick and easy installation.
Wide range of application
Generally suitable for refrigeration and air conditioning equipment, especially for ''dry'' evaporators, the superheat at the evaporator outlet is proportional to the evaporator load.
Pay Attention:
◆ Please check whether the product is intact before use
◆ Please confirm that the installation conditions are in accordance with the specifications
◆ Please use in a stable environment
◆ Pay attention to clean up dust and other things that affect operation
Main technical parameters
|
Type |
Connections |
Refrigerant (s) |
Equalization Connection |
Pressure Equalization |
Code no. |
|
|
Inlet |
Outlet |
|||||
|
TX2 |
3/8 '' (10mm) |
1/2 '' (12mm) |
R22/R407C |
1/4 '' (6mm) |
Int. |
068Z3206 |
|
TEX2 |
Ext. |
068Z3209 |
||||
|
TZ2 |
R407C |
Int. |
068Z3496 |
|||
|
TEZ2 |
Ext. |
068Z3501 |
||||
|
TN2 |
R134a |
Int. |
068Z3346 |
|||
|
TEN2 |
Ext. |
068Z3348 |
||||
|
TS2 |
R404A/R507 |
Int. |
068Z3400 |
|||
|
TES2 |
Ext. |
068Z3403 |
||||
|
Orifice no. |
Rated capacity in tons (TR) |
Rated capacity in KW |
||||||
|
R22 |
R407C |
R134a |
R404A R507 |
R22 |
R407C |
R134a |
R404A R507 |
|
|
0X |
0.15 |
0.16 |
0.11 |
0.11 |
0.50 |
0.50 |
0.40 |
0.38 |
|
00 |
0.30 |
0.30 |
0.25 |
0.21 |
1.0 |
1.1 |
0.90 |
0.70 |
|
01 |
0.70 |
0.80 |
0.50 |
0.45 |
2.5 |
2.7 |
1.8 |
1.6 |
|
02 |
1.0 |
1.1 |
0.80 |
0.60 |
3.5 |
3.8 |
2.6 |
2.1 |
|
03 |
1.5 |
1.6 |
1.3 |
1.2 |
5.2 |
5.6 |
4.6 |
4.2 |
|
04 |
2.3 |
2.5 |
1.9 |
1.7 |
8.0 |
8.6 |
6.7 |
6.0 |
|
05 |
3.0 |
3.2 |
2.5 |
2.2 |
10.5 |
11.3 |
8.6 |
7.7 |
|
06 |
4.5 |
4.9 |
3.0 |
2.6 |
15.5 |
16.7 |
10.5 |
9.1 |
Main Dimension
