P10 Indoor cheap price LED Billboard
3 year ago
Product Introduction
Indoor Fixed Advertising Led Billboard P10 indoor advertising LED billboards are a cost-effective option for
businesses looking to advertise their products or services indoors. The
P10 refers to the pixel pitch, which is the distance between each LED
pixel on the display. A P10 display has a larger pixel pitch, which
means the individual pixels are more visible from a closer distance for Fixed Led Billboards. Shopping Mall Led Display.
These LED billboards are easy to install and operate, and they come with
various features such as brightness adjustment, color temperature
adjustment, and remote control. They are energy-efficient and have a
long lifespan, which makes them a great investment for businesses. P10 indoor advertising LED billboards are a cost-effective and
practical option for businesses looking to advertise indoors.
Application
However, it is important to note that the image quality of a P10 display may not be as sharp as a display with a smaller pixel pitch. Therefore, it is important to consider the viewing distance and the content that will be displayed on the LED billboard before making a purchase.
Packing Solution
Packing Way: Wooden box
Data Sheet
|
MAIN TECHNICAL PARAMETERS FOR INDOOR LED DISPLAY(PITCH10) |
|||
|
（Technical parameters） |
UNIT |
（ parameters values ） |
|
|
（Pixel pitch） |
MM |
10 |
|
|
（Panel size） |
MM |
L320*H160*T13 |
|
|
（Physical density） |
/M2 |
10000 |
|
|
（Pixel configuration） |
R/G/B |
1,1,1 |
|
|
(Brightness） |
CD |
2000 |
|
|
（Driving method） |
|
1/8 Constant current 1/8scan |
|
|
（LED Encapsulation） |
SMD |
3528 |
|
|
（Display resolution） |
DOTS |
32X16=512 |
|
|
（Module weight） |
KG |
0.22 |
|
|
（Module port） |
|
HUB75 |
|
|
（Module working voltage） |
VDC |
5 |
|
|
（Module consumption ） |
W |
18 |
|
|
Panel Parameters |
|||
|
（Viewing angle） |
Deg. |
120 |
|
|
（Panel weight） |
KG |
35 |
|
|
（Option distance） |
M |
10-110 |
|
|
（Driving device） |
|
IC:2037/2153 |
|
|
（Every square metre module） |
PCS |
19.53125 |
|
|
（Maximum power） |
W/ M2 |
350 |
|
|
（Frame Frequency） |
HZ/S |
≥60 |
|
|
（Refresh frequency） |
HZ/S |
≥1920-3840hz |
|
|
（Equilibrium brightness） |
CD/ M2 |
≥1800-2000mcd |
|
|
（Working environment temperature） |
0C |
-10~60 |
|
|
（Working environment humidity） |
RH |
10%～70% |
|
|
（Display working voltage） |
VAC |
AC46～54HZ，220V±15%/110V±15% |
|
|
（Colour temperature） |
|
8500K-11500K |
|
|
（Gray scale/color） |
|
≥16.7M color |
|
|
（Input signal） |
|
RF\ S-Video\ RGB etc |
|
|
（Control system） |
|
NOvaStar Linsn Coloright |
|
|
（Mean free error time） |
HOURS |
＞5000 |
|
|
（Life） |
HOURS |
100000 |
|
|
（Lamp failure frequency） |
|
＜0.0001 |
|
|
（Antijam） |
|
IEC801 |
|
|
（Safety） |
|
GB4793 |
|
|
（Resist the electricity） |
|
1500V last 1min No breakdown |
|
|
（IP rating） |
|
The back IP40，The front IP50 |
|
|
（Steel box size） |
mm |
L960Xh960/640*640 |
|
