R290 Air to water Heating Cooling Hot Water monoblock dc inverter heat pump floor heating systems pump1
3 year ago
YK-03/BPKTR2 This series is our heating and cooling heat pump, which is a frequency conversion heating and cooling heat pump, which can
completely replace the air conditioner. It can provide cooling and heating for the room, as well as hot water service. One machine
has multiple functions to meet the needs of life.A R290 heat pump is a type of heat pump that uses propane (R290) as its refrigerant. Propane has a low global warming potential and is considered a more environmentally friendly alternative to traditional refrigerants. R290 heat pumps are commonly used in residential and commercial heating and cooling systems, as well as in refrigeration applications. They are known for their high efficiency and low operating costs, as well as their ability to provide reliable and consistent heating and cooling performance. However, it is important to note that propane is a flammable gas and proper safety measures must be taken during installation and operation.Air Source Heat Pump, Cooling Heat Pump, DC Inverter Heat Pump, Heat Pump, Pool Heat Pump, Water Source Heat Pump
has multiple functions to meet the needs of life.A R290 heat pump is a type of heat pump that uses propane (R290) as its refrigerant. Propane has a low global warming potential and is considered a more environmentally friendly alternative to traditional refrigerants. R290 heat pumps are commonly used in residential and commercial heating and cooling systems, as well as in refrigeration applications. They are known for their high efficiency and low operating costs, as well as their ability to provide reliable and consistent heating and cooling performance. However, it is important to note that propane is a flammable gas and proper safety measures must be taken during installation and operation.Air Source Heat Pump, Cooling Heat Pump, DC Inverter Heat Pump, Heat Pump, Pool Heat Pump, Water Source Heat Pump
| Model | YK-02/BPKTR2 | YK-03/BPKTR2 | YK-04/BPKTR2 | YK-05/BPKTR2 | ||
| Power Supply | V/Ph/Hz | 220~240/50-60/1 | 220~240/50-60/1 | 220~240/50-60/1 | 220~240/50-60/1 | |
| Heating Condition-Ambient temperature（DB/WB）：7/6℃，Water temperature（In/Out）：30/35℃ | ||||||
| Heating Capacity Range | kW | 4.1~9.2 | 5.4~12.2 | 6.8~15.2 | 8.2~18.2 | |
| Heating power Input Range | kW | 0.85~2.21 | 1.11~2.92 | 1.39~3.60 | 1.69~4.36 | |
| COP | W/W | 4.15~4.82 | 4.18~4.85 | 4.22~4.90 | 4.18~4.86 | |
| Heating Condition-Ambient temperature（DB/WB）：7/6℃，Water temperature（In/Out）：47/55℃ | ||||||
| Heating Capacity Range | kW | 3.9~8.7 | 5.2~11.5 | 6.5~14.3 | 7.8~17.1 | |
| Heating power Input Range | kW | 1.13~3.01 | 1.50~3.97 | 1.87~4.96 | 2.26~5.97 | |
| COP | W/W | 2.86~3.45 | 2.87~3.46 | 2.88~3.48 | 2.86~3.45 | |
| DHW Condition-Ambient temperature（DB/WB）：7/6℃，Water temperature（Start/End）：15/55℃ | ||||||
| Heating Capacity Range | kW | 3.8~8.6 | 5.1~11.3 | 6.4~14.1 | 7.6~16.8 | |
| Heating power Input Range | kW | 0.863~2.30 | 1.15~3.00 | 1.44~3.73 | 1.72~4.48 | |
| COP | W/W | 3.73~4.4 | 3.76~4.43 | 3.78~4.45 | 3.75~4.42 | |
| Cooling Condition-Ambient temperature（DB/WB）：35/24℃，Water temperature（In/Out）：12/7℃ | ||||||
| Cooling Capacity Range | kW | 3.08~6.7 | 4.05~8.8 | 5.57~12.1 | 6.08~13.2 | |
| Cooling power Input Range | kW | 0.905~2.39 | 1.19~3.16 | 1.64~4.32 | 1.79~4.75 | |
| EER | W/W | 2.8~3.4 | 2.78~3.38 | 2.8~3.4 | 2.78~3.39 | |
| Max. Power Input | kW | 3.7 | 4.8 | 5.7 | 6.8 | |
| Max. Current Input | A | 16.5 | 21 | 25 | 30 | |
| SCOP Level (35°C) | A+++ | A+++ | A+++ | A+++ | ||
| SCOP Level (55°C) | A++ | A++ | A++ | A++ | ||
| Working Ambient Temperature | ℃ | ﹣25~43 | ﹣25~43 | ﹣25~43 | ﹣25~43 | |
| Operating Water Temperature | ℃ | 7~70 | 7~70 | 7~70 | 7~70 | |
| Refrigerant | R290 | R290 | R290 | R290 | ||
