Modular Pressure Reducing Valve MBR-02P
2 year ago
Modular Pressure Reducing Valves MBR Series reduces the inlet pressure to a certain required outlet pressure through adjustment, and relies on the energy of the medium itself to automatically keep the outlet pressure stable. It is suitable for applications where a system requires different pressure outputs at the same time, and there is a requirement that two (or more) hydraulic circuits have the same pressure requirements.
Directional Control Valves like DSG Series Solenoid Directional Valves help you change direction of oil.And Pressure Reducing Valves help your hydraulic system maintain the safety.
Application
- Machine Tool Industry: CNC lathes, CNC milling machines, CNC band saws, circular saws.
- Drilling machines, special tapping machines.
- Bending Machine Industry: CNC tube bending machine, arc punching machine, tube end forming machine.
- Various industrial machinery such as small shears (within 30T), injection molding machines, various professional tool processing centers, clamps, high and low pressure pump circuits, hydraulic servo boring machines, shoemaking machines, plane grinder, rubber machine, injection machine, forklift, etc.
Specification
| MBR | 02 | P | 1 | K | 2H | 50 | C |
|---|---|---|---|---|---|---|---|
| Product Series | Port Size | Control Port | Pressure Adjusting Range (Bar) | Adjusting Type | Screw Length (Mm) | Knob Direction | Design No. |
| Modular Reducing Valve Series | 02: 1/4" |
P: P port A: A port B: B port |
1S: 1.5-35 1a: 26-31 1: 3-35 2: 8-70 3: 10-250 |
K: Knob (Standard Type) M10: Without Knob |
2H: 126.7mm (none1S) 3H: 156.7mm (only1S) 4H: 186.7mm (only1S) |
＊ 02-A/P： 50: B Port Side 51: A Port Side * 02-B： 51: B Port Side 50: A Port Side |
|
| 03: 3/8" |
1: 8-70 2: 8-140 3: 10-250 |
K: Knob (Standard Type) |
- | 50: B Port Side |
|
Conversion Table:
| MODEL | SIZE | ISO | CETOP | NFPA | DIN | |
|---|---|---|---|---|---|---|
| 02 | 1/4" | 6mm | ISO 03 | CETOP 3 | D03 | NG 6 |
| 03 | 3/4" | 9mm | ISO 05 | CETOP 5 | D05 | NG 10 |
Model Code
