Female Header
2 year ago
| Specification. | |
| Manufacturer: | YYE |
| Product Category: | Headers & Wire Housings |
| RoHS: | Details |
| Product: | Headers |
| Type: | Wire to Board |
| Number of Positions: | 6 Position |
| Pitch: | 0.8 mm |
| Number of Rows: | 1 Row |
| Row Spacing: | - |
| Mounting Style: | SMD/SMT |
| Termination Style: | Solder |
| Mounting Angle: | Right Angle |
| Contact Gender: | Pin (Male) |
| Contact Plating: | Tin |
| Termination Post Length: | - |
| Application: | Wire-to-Board |
| Minimum Operating Temperature: | - 25℃ |
| Maximum Operating Temperature: | + 85℃ |
| Packaging: | Reel |
| Contact Material: | Copper Alloy |
| Contact Type: | - |
| Current Rating: | 1 A |
| Flammability Rating: | UL 94 V-0 |
| Housing Colour: | Cream |
| Housing Gender: | - |
| Housing Material: | Thermoplastic (TP) |
| Insulation Resistance: | 100 MOhms |
| Latching Type: | Unlatched |
| Product Type: | Headers & Wire Housings |
| Subcategory: | Headers & Wire Housings |
| Voltage Rating: | 30 V |
The SUR series side entry shrouded header by YYE features a compact 0.8mm pitch design, making it an ideal choice for wire-to-board connectors and PCB applications. These connectors are single-row and disconnectable, offering insulation displacement capabilities. With a sleek profile, they boast a mere 3.9mm depth and stand at a height of just 1.75mm after secure mounting on the PCB. This fully shrouded header provides comprehensive protection, with walls encompassing all four sides to ensure proper connection to the mating housing. Additionally, it effectively safeguards against the intrusion of flux and other contaminants, making it a reliable choice for your PCB connector needs.
