road sweeper

Ⅰ.Product Overview

The road sweeper, mounted on a Dongfeng Class II chassis with National VI emission compliance, features an auxiliary engine that powers the fan and other working devices. It employs a suction sweeping and wet dust removal principle for road cleaning, enhanced by a symmetrical "four disc brushes in the middle plus suction nozzles in the rear" arrangement for thorough left and right side cleaning. This model leads in overall performance among similar products in China and holds multiple patents, such as for the "road sweeper cleaning device" and "road sweeper nozzle".

Product Advantages:

1. The road sweeper boasts a powerful cleaning capability, with a cleaning width of up to 3.1 meters and an efficiency rate exceeding 95%. It leaves pavements dust-free, stain-free, and water-free, significantly enhancing the quality of urban road cleaning.

2. The original "four brushes in the middle and one suction nozzle in the rear" symmetrical structure facilitates cleaning on both sides of the road. This layout is now widely imitated by most domestic well-known brands.

3. The sweeping brushes are equipped with a dust cover that can retract inward to avoid obstacles and automatically return to the normal working position once the obstacle has been passed.

4. The horseshoe-shaped suction nozzle, combined with the four middle sweeping discs, offers a strong suction force. It enables fast cleaning speeds and efficiently cleans a 3.1-meter wide road surface, with a maximum cleaning capacity of 62,000 m²/h.

5. The hydraulic system features a highly integrated, superimposed electromagnetic hydraulic valve group, which is neatly arranged, reliable in operation, and easy to maintain.

6. The road sweeper is equipped with a hand pump emergency system, allowing the dustbin to be retracted and lifted even when the auxiliary engine is stopped, facilitating maintenance.
