Sinotruk HOWO Fuel Tank Truck Tankers

Product Description
BEST COMPETITIVE PRICE WITH TRUSTED QUALITY

Specifications

Hongyan heavy duty oil tank truck, fuel tank truck:
1). Euro2, Euro3, Euro4, Euro5;
2). 20cbm, 25cbm, 28cbm, 30cbm;  35cbm, 40cbm.
3). B&V certificate

Fuel tanker series
1 Applied carbon steel sheet Q235-A;  Stainless steel;  Aluminium alloy that in accordance with the international standard.  Thickness is 5-10mm.
2 Apply the famous pump.
3 The main parts implements automatic welding, while the accessories apply carbon dioxide welding to ensure the tank in good performance.
4 Sub crossbeam apply rectangle steel sheet that thickness more than 5mm, stick out in one time.
5 Fire extinguisher replaced on the back of the truck for the emergency.
6 Painting held more tolerance and coherence, can make sure the tank in good situation more than 5 years.
7 According to customer's needs:
A> The pump can be designed to pump in and out throw meter, or not through meter, self-flow through or not through meter.
B> The tank can be designed as a single compartment or several compartments.
C> You can choose to install heating pipes, insulation layer.  The Insulation material is generally 50-100 mm thickness, insulation can be used rockwool, glasswool, polyurethane foam, aluminum silicate.  The cladding can be used 1.8-2mm thick white (RAL9003) glass reinforced plastic, 1.2mm cold carbon steel, 1.00mm stainless steel sub-mirror or matter board.
D> At the end or side of tank, It can be installed 1-3 self-flow valve.
E> You can chosse the type of the inlet and outlet (Europ standard or normally

Our main products:
1.  Dump Truck / Tipper Truck/Side Tipper/End Tipper
2.  Fire Fighting Truck / Fire Truck / Fire Vehicle / Fire Engine
3.  Truck with crane / Truck mounted crane
4.  LPG Tank Truck Trailer/Oil Tank Truck / Fuel Tanker Truck
5.  Water truck / Water Tank Truck / Water Sprinkler Truck
6.  Concrete Mixer Truck
7.  Van truck / Insulated truck/ Refrigeration truck
8.  Fecal suction truck / Sewage suction truck,
9.  Cement Powder Tank truck/ Bulk cement truck
10.  High-altitude operation truck,

11.  Self-loading garbage truck, garbage compactor truck, sealed garbage truck,

Hongyan heavy Oil Tank Truck
Technical Specification
Overall dimensions(L× W× H)			11990× 2500× 3750 ( mm )
Emission standard			Euro3
Cab			Single row, 3 passengers allowed in cab
G. V. W.			31000(kg)
Fuel type			Diesel
Engine & Chassis Specification
Chassis			CQ1315HTGG466V
Engine			SC10E350Q4
Max. speed			95(km/h)
Power			380(hp)
Displacement			10420(ml)
Axle base			1800+4265+1350(mm)
F/R wheel-base			2006, 2006/1850, 1850(mm)
F/R overhang			1435/2780(mm)
Axle load			6500/6500/18000(kg)
Tyre			Standard equipped 11.00-20 18PRranhou tyre
Tank   Specification
Tank dimensions			9000× 2500× 1800(mm)
Tank volume			25-30(cbm)
Tank material			Crabon steel Q235A, optional stainless steel & aluminium alloy
Tank thickness			5(mm), optional 6(mm)
Optional Choice
Accessories			Choosing Range
Standard equipments			Single gravity flowing wareroom, no pump, two aluminium alloy openings, warerooms, liquid level indicator, pump, watch, spool, measurement gun, manhole, AIP valve and oil-gas recovery systerm and so on are optional.
Tank material			Standard equipped the carbon steel as the tank material, and the carbon steel can be replaced by stainless steel or aluminum alloy or colored steel.
