Web Guide Tension Control Alignment System
2 year ago
Web Guide System For Corrugated Cardboard Production Line
Wideband Sensor detects web position
Optional Positioning towards center or outer liner
Serve drive technology guarantees precise and quick response
Minimizes power consumption, downtime, paper waste and operators attention
Precise and constant tension guaranteed
Consistent heating, uniform glue application and boards bonding optimized
User-friendly touch screen provides operating and maintenance inf
Best utilization of the paper width achieved
Sensor precision:1mm,Guiding precision：
±1mm,Guiding range:±50mm
Servo drive, high precision, fast response, equipped with paper pulling motor, convenient for 3/5/7 layer corrugated type conversion and feeding
Uniform and stable material tension with touch screen for diagnostics and maintenanceHigh precision - edge and core measurement accuracy ±1mm; width measurement is +-2mm
Reduce operator's work intensity and save cost, improve vehicle speed, efficiency and energy saving
|
Standard Configuration:
|
|
1. Web Guide System (German technology) + Tension Control System (Taiwan PLC)
|
|
2. German Osram LED detection electric eye
|
|
3.German Denke Dc motor, German B+F proximity switch
|
|
4.High-precision pneumatic brake, German Fosto electronically controlled proportional valve
|
|
5, Dedicated sun gear and sun gear bottom plate (the surface is plated with tungsten carbide)
|
A: Our factory is located in Foshan City, Guangdong Province, China.
For most of machines, engineers team provides solutions in the field of Mechanic/ Electric/ Operation.
TM online for 24 hours.
One year warranty period under normal use for most of machines.
