Standard transformer bushing insulator fittings
2 year ago
Standard transformer bushing insulator fittings
Transformer Accessories,Transformer bushing insulator accessories mainly include pure porcelain bushing, oil-filled bushing and capacitive bushing, Innovative Chip Radiator,High Efficiency Chip Radiator,High Temperature Resistant Transformer Bushing， these bushing according to the voltage level, adopt different designs and materials.
Pure porcelain bushing is mostly used for 10kV and below transformer, its structure is relatively simple, is mainly composed of conductive copper rod and porcelain sleeve, porcelain sleeve filled with air as insulation medium.
Oil-filled bushing is mostly used for 35kV transformer, it adds oil-filled design on the basis of pure porcelain bushing, is filled with insulation oil inside the porcelain bushing, at the same time conductive copper rod with insulating paper, to improve insulation performance.
Capacitive bushing is used in the high voltage transformer of 100 kv, its structure is relatively complex, outside by the main insulation capacitor core, insulation porcelain, connecting sleeve up and down, oil pillow , spring assembly, base , equalizing goal, measuring terminal, , rubber washer terminals and insulating oil, etc. The bushing can withstand higher voltage levels and provides more reliable electrical insulation.
