mini circuit breaker 10a
2 year ago
SVLEC produces Electronic Circuit Breaker, including 4-port and 8-port electric circuits. We mainly produce small power electric breaker, 1-10A. Our electronic circuit breakers provide reliable overload protection and short circuit protection. The channel density is high and can parasitize the space of the control cabinet. The rated current of each channel can be set individually. It complies with the EN 60204-1 standard and can reliably cut off ground faults within five seconds. We also carry the IO-Link communication protocol, and the loop communication speed has advantages over other methods. Our electronic circuit breakers can be used in conjunction with power modules, Bus Module, Connectors and other automation field Accessories.
Ordering information
4 Port with IO-Link
8 Port with IO-Link
No.
760002
760012
Technique data
Input working voltage
24 V DC (18...30V DC)
Output current regulation
1A,2A,3A,4A,5A,6A,7A,8A,9A,10A
Output impact capability
20mF maximum (per channel)
control input voltage（on）
10...30 V DC
Control pulse width
min.20ms
Control output overall alarm output
Dry junction alarm output 30V AC/DC,100mA
