Full Automatic Count Paper

11 month ago

11 0 

Ruian Tiancheng Packing Machinery Co., Ltd.

4 year

Product details

Product Paramenters

Packing machine
No	Item	Data
1	Model No.	TCJ-QSJ700
2	Product	paper cup/paper bowl
3	Top Diameter	Φ60mm-Φ95mm /Φ95mm-Φ150mm ( other size can be customized)
4	Max. Stacking length of cups	630mm/720mm
5	Packaging material	HDPE.LDPE.PP.POF.PO
6	Packaging film thickness	12μm-50μm
7	Max speed	18bags/min
8	Max. torque	500N.m

Case machine
No	Item	Data
1	Max.Packaging Speed	Speed 12 sleeves /min
2	Effective cup Diameter	Φ60mm-Φ150mm
3	Carton Length	350mm to 500mm( other size can be customized)
4	Carton Width	240mm to 450mm( other size can be customized)
5	Carton height	330mm to 600mm( other size can be customized)
6	Electrical Req	0.8KW one phase 220V 50HZ/60HZ
7	Air Req	0.6MPa

Product Overview

TCJ-QSJ700

Full-automatic plastic cup (bowl) packing machine (Laser count) 1.Plastic cup packing machine is one of the necessary equipment in modern Plastic cup production and it is the best option to replace manual work. 2.First it solves the problem about the dust and fingerprint which is a big problem in manual work. 3.Second it can reduce labors and save lots of packing materials. 4.Thirdly,the packaging result is more beautiful than hand bag packaging.
