Steel Structure Workshop

    Steel structure warehouse is the same as steel structure workshop, is a lightweight steel structure product, with the main structure being cold-formed thin-walled steel components connected by bolts. The span of one unit can reach 30 meters, and it can also be combined with another unit to achieve multi span space. Compared with traditional steel structure buidings, it has advantages such as light weight, large span, fewer materials, low cost, saving foundation, short construction period, safety and reliability, and beautiful appearance. It is an ideal choice for large and small steel building.Steel structure buildings warehouses are more cost-effective than other traditional concrete block building systems because steel is a super strong material that can use fewer materials to achieve the same structural scale. All steel frame components are cut, welded, drilled, and painted in the factory. They can be bolted together as soon as they arrive at the construction site.

Related building types: commercial, industrial, manufacturing, medical, small warehousing, warehousing buildings

Steel structure warehouse material components
1. Type: Double slope or multi slope; Single span or multiple spans; Single or multiple layers
2. Base: Concrete and steel anchor bolts.
3. Columns and beams: made of Q345 or Q235 steel, fully bolted, with straight or variable cross-sections
4. Support: An X or V-shaped or other type of support made of angle steel, round pipes, etc.
5. C or Z purlins: size C100~C320
6. Roof and wall panels:
Single layer colored corrugated steel plate, thickness: 0.326-0.6mm.
Sandwich panels with insulation materials such as EPS, rock wool, PU, etc., with a thickness of approximately 50mm~150mm.
7. Accessories: skylight, ventilator, downpipe, gutter, etc.
8. Steel surface: painted or hot-dip galvanized.

    In short, steel structure warehouses are known for their sturdy steel skeleton and efficient modular design. This type of warehouse usually has open internal space, and the columnless design makes space utilization high, making it convenient for large-scale mechanical operations and cargo storage. The rapid assembly feature shortens the construction cycle while providing good seismic performance and a longer service life. Surface coating treatment enhances corrosion resistance and is suitable for various climatic conditions. The drainage system adopts PVC drainage pipe.Overall, steel structure warehouses are the ideal choice for modern logistics warehousing, combining economy and functionality.
