TEMPERATURE RANGE：-40℃~+121℃（-40°F~+250°F）
The SAE 100R9 Steel Wire Spiral Hydraulic Hose is a high-quality, durable hose that is designed for use in hydraulic systems. Rubber Hose is constructed with a wire spiral reinforcement that provides excellent strength and flexibility, making it suitable for a range of applications. Steel Wire Hose is made from oil-resistant synthetic rubber, which ensures that it can be used with a variety of hydraulic fluids. It meets SAE standards, ensuring that it is reliable and safe to use in hydraulic systems. This hose is ideal for use in industrial applications that require high-pressure hydraulic performance, such as construction machinery, mining equipment, and agricultural machinery. It is available in a range of sizes to suit different applications, making it a versatile choice for any hydraulic system.
| SIZE (Dash) | SIZE (in.) | I.D. (mm) | O.D. (mm) | Max.W.P. | Min.B.P. | Min.B.R. | |
| Min | Max | Max | (MPa) | (MPa) | (mm) | ||
| 10 | 3/8 | 9.3 | 10.1 | 22.2 | 31.5 | 126 | 125 |
| 13 | 1/2 | 12.3 | 13.5 | 25.4 | 28 | 112 | 180 |
| 19 | 3/4 | 18.6 | 19.8 | 32.2 | 21 | 84 | 240 |
| 25 | 1 | 25.0 | 26.4 | 40.9 | 21 | 84 | 300 |
| 32 | 1 1/4 | 31.4 | 33.0 | 52.4 | 17.5 | 70 | 420 |
| 38 | 1 1/2 | 37.7 | 39.3 | 58.7 | 14 | 56 | 500 |
| 51 | 2 | 50.4 | 52.0 | 73.0 | 14 | 56 | 660 |
Note: The actual parameters are subject to the final atlas
