outdoor video panel in the rain

Feature :

1, 5W Output RGBWW led

2, New Optical Design with 25° Beam Angle, can throw 100M distance,( 63698926,optional 10°  with 200M throw distance)

3, IP65 waterproof

4, 2,700K to 10,000K CCT with Green-Magenta Adjustment

5, more than 10 special effects for film lighting application: ccandle, cloud passing, club, color chase, cop car, fire, fireworks, strobe,lightning, paparazzi, pulsing, television

6, CRI>96

7, TLCI>98

8, Multiple Control modes: DMX/RDM, Bluetooth App Control, LumenRadio CRMX

Specification:

Input voltage： AC100-240V, 50-60HZ

led source： 1800W RGBW led, RGB WW CW each 360W

Power consumption：360W Maximum

CCT ： 2700-10000K +-100k

Colored Light： Full RGB+W Color Gamut with Hue and Saturation Control

Green-Magenta Adjustment： Continuously adjustable (Full Minus- to Full Plus green)

Color rendering： Average CRI>97，average TLCI >98

beam angle： 25°

Control mode：DMX512, RDM

Integrated wireless control：Bluetooth App Control, LumenRadio CRMX

Color modes CCT, HSI, GEL, RGBCW, CIE (XY Coordinates)

Dimming performance： 8 bit and 16bit, Flicker free，high-res low end dimming

Dimming curve： 4 kinds

Pixel zones： 4

LCD display： LCD touch screen + two knobs

Cooling system： Low noise fan with IP

Dimension： 737*384*180mm

N.W 19.7kg

Battery DC Voltage Range 24V

Special effects: candle, cloud passing, club, color chase, cop car, fire, fireworks, strobe,lightning, paparazzi, pulsing, television

IP rate： IP65



for more IES data, please contact EV LIGHT sales team @Kate Chen
