flap disc
3 year ago
APPLICATION:
Zirconia alumina flap discs are ideal for grinding, stock removal, beveling, weld blending, deburring, rust removal, cleaning and finishing.
Applied on rust, paint, ferrous, stainless steel, non-ferrous metals, wood and plastics.
T27 flat shape mainly used for grinding flat surfaces, most efficient when used at a 0-15 degree angle
T29 Conical shape provides an excellent angle for contonur and edge grinding, best at a wider angle of 15 to 25 degree
We provide full range of abrasive flap disc for different applications
Below are the parts of common used size in the market, any other size can be customized. Please contact us for any other special size
|
Out Diameter |
Out Diameter |
Backing |
Abrasive |
|
90mm. |
16mm |
Fiberglass backing 5-8 layers |
Zirconia, ceramic, A/O |
|
100mm. |
16.2mm |
Fiberglass backing 5-9 layers |
Zirconia, ceramic, A/O |
|
115mm. |
22.2mm |
Fiberglass backing 6-10 layers |
Zirconia, ceramic, A/O |
|
125mm. |
22.2mm |
Fiberglass backing 7-10 layers |
Zirconia, ceramic, A/O |
|
150mm. |
22.2mm |
Fiberglass backing 7-12 layers |
Zirconia, ceramic, A/O |
|
180mm. |
22.2mm |
Fiberglass backing 7-12layers |
Zirconia, ceramic, A/O |
|
230mm. |
22.2mm |
Fiberglass backing 10-14 layers |
Zirconia, ceramic, A/O |
