SZG Vacuum Double Cone Dryer
Attention to order:
2. when order the SZG Vacuum Double Cone Dryer, client need to supply the dry powder density residual water contents allowed, particle size, and maximum temperature allowed.
3. Output: shift time daily.
4. when order the SZG Vacuum Double Cone Drier, client need to supply the energy that can be supplied: steam pressure, electricity properly, fuel of coal, oil and natural gas.
5. Control requirement: whether or not the inlet and outlet temperatures should be controlled.
6. Other special requirements.
Product Features:
1. Vacuum Double Cone Dryer is mainly suitable for the following materials to be dried in pharmaceutical, foodstuff and others industries.
2. The container of the Vacuum Double Cone Dryer rotates continuously so as to renew surfaces of heating materials.
3. Vacuum Double Cone Dryer adopts Indirect heating approach and unpolluted material.
4. Rotary Vacuum Dryer will be increased by over two times in heat efficiency compared with the general one.
5. Low temperature, Rapid drying and Mixed powder.
6. The material in the Vacuum Dryer is heated by steam or hot water.
7. Machine materials : 304 stainless steel, 316L stainless steel, or other material .
Vacuum Double Cone Dryer Application
This Vacuum Dryer can be widely used for drying or mixing powder or granule materials in pharmaceutical, chemical, foodstuff industries etc.
The main technical datum of the vacuum drying equipment is for reference. We also produce and design product as per customers' requirement.
| Type of the vacuum dryer | SZG-0.1 | SZG-0.3 | SZG-0.5 | SZG-1 | SZG-2 | SZG-3 | SZG-4 | SZG-5 |
| Volume(L) | 100 | 300 | 500 | 1000 | 2000 | 3000 | 4000 | 5000 |
| Material feed factor | 0.4-0.6 | 0.4-0.6 | 0.4-0.6 | 0.4-0.6 | 0.4-0.6 | 0.4-0.6 | 0.4-0.6 | 0.4-0.6 |
| Max material feed weight(kg) | 50 | 120 | 200 | 400 | 800 | 1200 | 1600 | 2000 |
| Vacuum of the drying machine | Dg50 | Dg50 | Dg50 | Dg50 | Dg70 | Dg100 | Dg100 | Dg100 |
| Condensed water in the machine | G3/4" | G3/4" | G3/4 | G1" | G1" | G1" | G1 1/2" | G1 1/2" |
| Motor power(kw) for drying | 1.1 | 1.5 | 2.2 | 3 | 5.5 | 7.5 | 11 | 15 |
| Total weight(kg) | 650 | 1200 | 1450 | 2800 | 3580 | 5950 | 6450 | 7300 |
