 Composition structure of photovoltaic energy storage harness

The photovoltaic energy storage harness is mainly composed of wires, connectors, insulating sleeves, identification tubes and protective sleeves, as follows:

1. Battery Wiring Harness: Connecting photovoltaic modules, inverters and battery modules, it is the main part of power transmission and needs to have good conductivity and corrosion resistance.

2. Connectors: Connecting wires and photovoltaic modules, inverters and battery modules, it needs to have good contact and reliability.

3. Insulating sleeves: used to protect wires and connectors from the influence of the external environment, it needs to have good insulation and heat resistance.

4. Identification tubes: used to identify the functions and specifications of the harness for easy maintenance and management.

5. Protective sleeves: used to protect the harness from damage during transportation and installation, it needs to have good protection and wear resistance.

We also provide Battery Cable Assembly and Battery Cable harness.
