Gloss Meter CS-300 SE Operation Introduction
4 month ago
CHNSPec CS-380 SE High Precision 100000 Ultra Long Endurance Cycles Gloss Meter
*Lithium ion battery charging saves users on usage costs while ensuring an ultra long battery life of 100000 times
*Each instrument includes a measurement report, saving customers 500 yuan in measurement fees
*A single machine can store 5000 pieces of data, solving the problem of user data storage
*Standard QC software, data can be stored on the computer and reports can be exported
*Adopting a 320 * 240 color screen, the data display is clear at a glance
*Meets the requirements of JJG 696-2015 glossmeter for more accurate data
*Adopting a universal Type-C interface to reduce user procurement costs
| Model | CS-380 SE |
| Measuring Angle | 20°,60°,85° |
| Measuring light spots(mm) | 20°:10*10;60°:9*15;85°:5*38 |
| Measuring range | 20°:0-200GU;60°:0-200GU; 85°:0-100GU |
| Display resolution | 0-100:0.1GU;>100:1GU |
| Measurement repeatability accuracy | 0-100GU:0.2GU;100-200GU:0.2%GU |
| Measurement mode | Simple mode and statistical mode |
| Measurement accuracy | Meet the requirements of JJG 696-2015 |
| Measurement time | <1.5s |
| Data storage | 5000 pieces of data |
| Volume | 165*51*77mm(L*W*H) |
| Weight | 400g |
| Language | Chinese,English |
| Battery capacity | 3000mAh lithium battery |
| Electricity level | Fully charged, can be used 60000 times |
| Interface | Type-C |
| Screen size | 2.4 inches(Screen resolution320*240) |
| Computer software | Yes |
| Working temperature | 0-40ºC |
| Working humidity | Less than 85%, no condensation |
| Accessory | 5V/2A charging head, data cable, manual, USB flash drive (upper computer software), calibration standard board, third-party calibration certificate |
| Purpose | Paint and ink, coatings, electroplating, plastic electronics, hardware and other fields |
