powder square cone mixer
3 year ago1.WHY CHOOSE US
The machine has novel design, compact structure, beautiful appearance, mixing uniformity up to 99%, volume loading coefficient up to 0.5.
Low rotary height, smooth operation, reliable performance, easy to operate.
The inner and outer walls of the barrel are mirror polished, no dead Angle, easy to discharge, easy to clean, no cross contamination, in line with GMP requirements
2.WORKING PRINCIPLE
The material is put into the square conical closed mixing barrel, the symmetrical axis of the hopper and the axis of the rotating axis form an Angle, the different components of the material in the closed hopper for three-dimensional space movement, strong flipping and diffusion contraction effect, to achieve high quality mixing effect.
3.MAIN APPLICATION
It's a novel material mixer widely used in pharmaceutical, chemical, metallurgy, food, light industry, feed and other industries. The machine can mix powder or particles very evenly, so that the mixed material to achieve high quality effect.
4.KEY PARAMETER
Model
Max fed volume(L)
Max fed capacity(kg/batch)
Spindle speed(rpm)
Motor(kw)
Size(mm)
Weight(kg)
FH300
240
150
14
1.5
2010x1250x1800
500
FH500
400
250
13
2.2
2200x1530x2220
700
GH1000
800
500
12
4
2800x2000x2820
1000
GH1500
1200
750
10
5.5
2930x2300x2950
1500
FH2000
1600
1000
8
7.5
3100x2460x3160
2000
FH3000
2400
1500
6
11
3350x2820x3800
3000
Remarks:
1.Delivery:15 working days in factory
2.Payment:30% advance,70% before shipping by Paypal/TT
3.We are manufacturing company with the factory price and high quality
4.We can provide offer with FOB,CIF,CFR as consumer requirements
5.If u feel interested in this double spiral cone mixer or screw conveyor or sifting machine or spices pulverizer or rotary vacuum dryer or powder mixer machine or capsule blister packing machine or capsule filling machine or capsule polishing machine or capsule counting machine or tablet press etc someday that we produced u can tell me your specific requirement so that i can better recommend more suitable for your demands machine,what do u think
