UL 3122 20# WHITE WIRE
6 month ago
Certification standard: This wire complies with UL 3122 standard, which is one of the safety standards set by UL for wires and cables.
Wire specification: 20# refers to the specification of the wire. The "#" here is AWG (American Wire Gauge) American wire gauge unit. 20# means that the conductor diameter is about 0.8128 mm. The larger the AWG value, the thinner the conductor; the smaller the value, the thicker the conductor.
Color: WHITE (white), indicating that the outer sheath color of the wire is white, which is convenient for distinguishing wires for different purposes during installation.
CHARACTERISTIC:
High temperature resistance, low temperature resistance, anti-acid, anti-oil, anti-sepsis and moisture, fire and aging resistance, the inoxidizability, resistance of humidity, the fine electric insulation and flexible performance UL758, UL1581/2556, ROHS compliance.
- Safe and reliable: UL certified to ensure the safety of the product.
- High-quality materials: High-quality copper is used as the conductor material to ensure the good conductivity of the wire.
- Strong durability: The insulation layer of the wire is usually made of materials such as PVC (polyvinyl chloride), which has good physical and chemical stability.
- Easy to install: The white appearance is simple and elegant, easy to identify, and the soft characteristics make installation more convenient.
APPLICATION:
Suitable for household appliances, lighting fixtures, electronic equipment, temperature sensors, aerospace, military products, metallurgical and chemical industry, communications, automobile and ships, electric power installation and other connecting lines.
Our company mainly includes UL Wire Series, CUL Wire Series, Silicone Wire Series and Electric Heaters Series, Electric Tracing Tape Series, etc. If you need more detailed technical parameters or application suggestions, please contact us.
