Production description
The transmission part of ZXF-80Z automatic metal hose filling and sealing machine is closed below the platform, which is safe, reliable and pollution-free; the filling and sealing part is installed in the semi-closed non-static outer frame visual cover above the platform, which is easy to observe and easy to observe. Operation, easy maintenance; fault alarm, overload shutdown or counting and quantitative shutdown.
Application
It is used for tube packaging needs of medicine (burn ointment), food (peanut butter), cosmetics, skin care products (whitening cream), daily chemicals (shoe polish) and other industries.
Main Feature:
Pneumatic Tube Washing & Feeding
Intalligent Temperature Controf and Cooling System
316L Stainiess Steel Contact Parts to meet GMP Standard
Automated Working process from Tube Loading to Finished Products Output
Automatic Onentation Effected by Photoelectric Induction
Technical Parameters
|
Filling volume: |
1-300ml/unit(Adjustable) |
|
Filling accuracy: |
≤±0.5% |
|
Capacity: |
2400-4800unit/hour,Adjustable |
|
Tube diameter: |
Ǿ10-35mm |
|
Tube length: |
210mm |
|
Hopper volume: |
40L |
|
Power: |
380V/220V(Optional) |
|
Air pressure: |
0.4-0.6Mpa |
|
Machine power: |
2KW |
Sealing Type
Two-tailed
three-tailed
saddle tailed
Workflow:
tube bin (hose container) → automatic tube loading → identification and positioning → hose internal cleaning (option) → filling → tail hot melt → pressing and sealing, typing code → (flat tail) → one folding → two Secondary folding→saddle folding→cutting (printing code on metal tube)→finished product discharge.
