| PRODUCT PARAMETERS | |||
| Model | HT-SSA2 | HT-SSA3 | HT-SSA4 |
| Laser power | 1500W | 2000W | 3000W |
| Operating mode | Continuous or modulated | ||
| Laser wavelength | 1064NM | ||
| Beam quality | M2<1.15 | M2<1.2 | M2<1.2 |
| Output power stability | ±2% | ±2% | ±2% |
| Power requirement | AC220V±10%50/60Hz | 380V±10%3P+PE | 380V±10%3P+PE |
| Overall power | ≤9KW | ≤12KW | ≤15KW |
| Cooling system | The customized industrial chiller features dual temperature and dual control capabilities | ||
| Fiber length | 10-15M customizable | ||
| Operating ambient temperature range | 15-35℃ | ||
| Working environment humidity range | ＜70% No condensation | ||
| Welding thickness range | MAX 4mm | MAX 6mm | MAX 8mm |
| Applicable material | Aluminum, cold binding, carbon steel, stainless steel, galvanized sheet and other metal materials | ||
| Weld requirement | ＜2mm | ||
| Welding speed | 0-120mm/s | ||
Our main products are Hot-dip galvanizing nuts、Stainless steel bolts、Handheld laser welding machine and so on.
Please contact us if necessary. Look forward to your sincere cooperation.
