stevia leaf grinding machine

Main application

ZFJ Series Chinese herbal medicine pulverizer machine is mainly used for the relatively high speed movement between the movable cutter head and the gear ring, so that the fiber is shear crushed, the movable cutter head has three different tool combinations of coarse crushing, medium crushing and micro crushing, the crushed finished products are separated by the cyclone to obtain the finished products, the over crushed dust by the cloth bag dust recovery. This machine is made of stainless steel, bearing and grinding box grading have water

cooling device; The gear ring is an arc serrated spiral. Continuous discharge, no dust flying in the production process, in line with GMP requirements. Also,this is a tea leaf grinding machine and a herbal leaf milling machine.

The pulverizer has a main machine, auxiliary machine, collection pipe, electric control device for a group, auxiliary machine has a cyclone and a cloth bag dust collector. The main machine contains centrifugal classification device, in addition to complete the crushing, but also has the classification function, separation type centrifugal shear, no screen no net, powder particles can be arbitrarily adjusted, the material is crushed, using negative pressure conveying discharge valve port, to meet the requirements of products. The superfine herbal powder pulverizer machine is an ideal machine for pharmaceutical, food and chemical industry.

Technical data
