Neodymium Magnet 45″ Drone Motor
4 week ago
| Main Application | Used for drone motors |
| Place of Origin | Ningbo, China |
| Brand | SHINE |
| Grade | N52SH |
| Type of Coating | Zinc Coating |
| Size | R14.4xr12.7xW3.2xL5.6 (mm) |
| Processing Service | Shaping, Sintering, Cutting, Plating |
| Packaging | Antirust paper, gasket, vacuum packaging, inner cell foaming material, carton, plastic box, protective pallet transportation |
| Transport | Express delivery, logistics, sea or air transportatio |
| Re: The data above is only for your reference. Please contact us for more details. | |
Used for brushless motors in multi rotor and fixed wing unmanned aerial vehicles to enhance hover stability, climb efficiency, and dynamic response, meeting the needs of aerial photography, agricultural crop protection, logistics transportation, and other scenarios.
2. High precision industrial motors
Suitable for micro servo motors, stepper motors, and high-precision control fields such as industrial automation robots and medical equipment.
3. Customized solutions
Provide magnetic circuit design optimization services to support customized motor requirements for extreme environments (low temperature, strong vibration) in multiple fields.
Magnetization Direction
The following are the conventional magnetization methods. If there are special magnetization requirements, please contact us for consultation!
Can I place the magnets nearby cellphone or other electronic products?
It is no problem for for the magnet in small size such as D8x1mm. But for bigger one such as D50x30mm, we do not suggest you to place the magnets nearby the cellphone. Please be cautious that keep all magnets far away from pacemaker!
Do you have finished magnets in stock?
There are too many specifications of magnets. Different customers needs different grades, sizes, shapes, magnetization orientation, plating, tolerance. So we often make the quantity as customer ordered. For the long-terms customers who frequently buy the same magnets from us, we may have some in stock. Please contact us if you want to know what we have in stock.
What is the max. and min. size of magnet you can make?
We can make the magnet in size from 1x1x0.5mm to 200x100x60mm in block shape and from D1x1mm to D200x50mm for disc magnets. Our sales guy is ready to provide you size details if you need.
Could magnets be delivered by air for urgent demand?
Magnetic shield is necessary for the magnets to be delivered by air. We will put iron plates inside the carton to shield the magnetic force. So you need to inform us if the magnets are delivered by air.
Is surface treatment necessary for neodymium magnets?
The composition of neodymium magnets is mainly neodymium, Iron and boron. The percentage of iron is up to 60%. So it is easy for neodymium magnets to get rusty. The normal plating of neodymium magnets is Zinc, NiCuNi, Epoxy etc. Zinc plating works in dry and clean condition. NiCuNi and Epoxy could be used in humid or bad working condition.
How to choose the grade of neodymium magnets?
The magnetic properties of neodymium magnets could be reduced in the working temperature that exceeds the magnet could stand. So working temperature is a very important factor to decide the grade of neodymium magnets. For example, if the magnets work in the temperature of 110 degrees, you need to buy neodymium magnets at least in H grade. If the working temperature of magnet exceeds 200 degrees, SmCo magnets or AlNiCo magnets is the best solution.
Br is another factor you need to take into consideration. Higher Br is necessary if you need very powerful magnet. We are always glad to give you professional suggestions about how to choose the grade of magnets
