Full Automatic epoxy resin Two component potting machine TH-2004D-2004AB11
3 year ago
2 component metering & mixingdispensing robot Automatic epoxy resin potting machine with cleaning function TH-2004AB2
Product introduction
The touch screen controller can realize automatic feed AB epoxy resin, automatic defoaming treatment, automatic stirring,
automatic mixing, It is used for potting of ab glue and epoxy in various lamps, appliances, electronics and other industries.
TH-2004AD-2004AB1
Function
Liquid Materials
AB GLUE.epoxy resin,PU GLUE,Two component material,two part mixing material
Features
1. The whole bucket of glue only be placed on the tank side of the machine, and the equipment can be automatically extracted
without manual pouring into the storage bucket.
2. The storage tank can be customized according to the potting of AB glue in each hour.
3. The storage tank has automatic defoaming function and material location level detection function.
4. The tank can be customized according to your glue need, such as: automatic stirring, automatic constant temperature, air
drying, etc. ..
5. High-precision screw pump (gear pump / plunger pump) pushes glue through the cavity, with high pressure and fast glue output.
6. The servo motor drives the screw pump , the speed of each pump can be set separately, to keep the flow speed of each pump, To
achieve the required mixing ratio (1: 1--1: 10 adjustable).
7. Equipped with dynamic mixing device to make the mixing of glue more uniform.
8. Equipped with automatic cleaning function, no need to manually cleaning the machine, avoid manual cleaning trouble.
9. Equipped with 500 * 500mm mechanical arm, which can edit the running path, To actual perfect potting ab glue at correct
location on product.
service Free
Help you seek the glue.
Free offer trial video for your sample.
Free training with machine.
Free offer accessories dispensing kit.
Save cost
One machine instead of three or four staff, reduce the management cost, also can work for 24 hours.
Help your business
You can bring customers to visit your workshop,the equipment to produce customer satisfaction products,then take good business for you
Specification
ITEM | TH-2004AD-2004AB1 |
Standard | CE Approved |
Mixing ratio | 1:1-1:10 |
Viscosity range | 1-30000cps |
Mixing method | Dynamic stirring |
Control method | Touch Screen/PLC Mitsubishi |
Anti-crystallization | Dry filtration |
Anti-sedimentation | Keep stirring in running |
Defoaming | Vacuum negative pressure |
Tank | 40liter(2pcs) |
