PEEK ESD sheet rod

HONYESD®PEEK Antistatic Poly Ether Ether Ketone Sheet is static-dissipative, carbon fiber reinforced PolyEtherEtherKetone for use where the properties of PEEK are needed, but protection from static discharge is a requirement. This material is available in sheets and rods and is black in color.ESD Antistatic PEEK is an antistatic, nano-carbon fiber-reinforced PEEK with exceptional mechanical strength, toughness, flexural strength, torsional strength, Antistatic PEEK has excellent chemical resistance, very good dielectric properties and temperature resistance up to 482F (250°C) , and excellent resistance to various types of radiation. Static values are 10^6-10^9.

Black ESD PEEK Features:

1: High temperature resistance, even if the temperature reaches 300 ° c, it can still maintain excellent mechanical properties

2: Wear resistance, in many extremely harsh application environments such as high temperature, high load, and strong corrosion, PEEK and its composite materials have Excellent wear resistance.

3: Self-lubricating, low friction coefficient peek450g 0.30-0.38 peek450ca300.28 peek450gl3000.38-0.46 peek450fc3000.18. It can realize oil-free lubrication and work for a long time in media such as oil, water, steam, weak acid and weak alkali.

4: Corrosion-resistant, insoluble in common solvents, and has good corrosion resistance to various organic and inorganic chemical reagents.

5: High strength, with the best mechanical strength in plastics. It also has high hardness and surface hardness.

6: Easy to process, it can be processed directly from injection molded parts. Post-processing such as turning, milling, drilling, tapping, bonding and ultrasonic welding is possible.

7: Hydrolysis resistance, under steam temperature above 250 °C or high-pressure water immersion, PEEK products can continue to work for thousands of hours without obvious performance degradation.

8: Flame retardant. The flammability rating for the 1.45 mm peek sample was UL94 V-0 without the use of any additives.

9: Low smoke and non-toxic, the volume of combustion smoke and toxic gas is particularly low.

10: Electrical performance, in a wide range of temperature and frequency, it can still maintain stable and excellent electrical performance.

11: Anti-radiation, with strong resistance to high-dose gamma-ray radiation, mechanical properties can be fully maintained, and can be used as anti-radiation components in nuclear equipment. Strippability Peep has good strippability, so it can be made into extremely thin-coated or electromagnetic wires, and can be used in harsh conditions. Chemical resistance (corrosion resistance) peek has excellent chemical resistance. In common chemicals, the only thing that can dissolve or destroy it is concentrated, which is almost as resistant to corrosion as nickel steel.

Esd Antistatic Peek Sheet is added with multi-wall CNT carbon nanometer 2~5wt% tube to achieve anti-static and anti-static functions.


PEEK has the heat resistance and chemical stability of thermosetting plastics and the molding processability of thermoplastics. The long-term use temperature of PEEK is about 260-280°C, the short-term use temperature can reach 330°C, and the high pressure resistance can reach 30MPa. It is a good material for high-temperature sealing rings. PEEK products are suitable for various environments with harsh working conditions. PEEK also has excellent properties such as good self-lubrication, easy processing, stable insulation, and hydrolysis resistance, making it widely used in aerospace, automobile manufacturing, electrical and electronic, medical and food processing and other fields. Due to the unique performance advantages of PEEK materials, PEEK products can be widely used in many fields such as petrochemical, electronic and electrical, instrumentation, machinery and automobile, medical and health, aerospace, military nuclear energy and so on.

PEEK materials are used in aerospace, PEEK and PI materials are used in fuel filter support seats, bolts, nuts and bobbins in the aviation industry due to their excellent performance, rocket battery slots and rocket engine parts, etc. .


PEEK materials are used in the machinery industry, and PEEK products are widely used in the machinery industry to manufacture compressor valve plates, piston rings, seals, and various chemical pump bodies and valve components.

PEEK materials are used in the automotive industry. PEEK materials can replace metal, stainless steel and titanium, and are used to manufacture engine inner covers, bicycle gaskets, bearings, clutch gears, seals and other parts. In addition, PEEK materials can also be used in In the transmission, brake and air conditioning system of the car.

PEEK materials are used in petrochemical industry, PEEK materials and special composite materials can be used in digital logging, subsea integrated pipe bundles, electrical connectors, cable ties, seals, support rings, plugs, packers, fracturing balls, centralizers, wires cables etc.

PEEK materials are used in medical devices, and PEEK materials can be used in precision medical instruments: such as PEEK microwave digestion tanks, tooth plates, artificial bone slices, and straight boosters.

PEEK materials are used in instruments and meters. PEEK materials are often used to manufacture chromatograph connectors, wafer carriers, electronic insulating diaphragms and various connecting devices. They can also manufacture wafer carrier insulating films, connectors, printed circuit boards, and high temperature connectors Inserts, suction nozzles, plating wheels, etc.
