Hot-Dipped Galvanized Steel Coils
3 year ago
PRODUCT DESCRIPTION
Hot-dip Galvanized Steel coils, also known as zinc coated Steel Coils, is to dip a thin Steel Sheet into a molten zinc bath to make a layer of zinc adhere to its surface. Hot dipped Galvanized Steel Sheet In Coil is mainly produced by continuous galvanizing process, that is, the coiled steel sheet is continuously dipped in a plating tank with molten zinc to make Galvanized Steel Sheet and alloyed galvanized steel sheet. This kind of steel panel is also made by hot dip method, but it is heated to about 500℃ immediately after coming out of the tank, so that it can form an alloy film of zinc and iron. This galvanized coils have good paint adhesion and weldability.
| HOT-DIP GALVANIZED STEEL COILS GI COIL | ||||
| ASTM A653M-06a | EN10327:2004/10326:2004 | JIS G 3302-2010 | AS-NZS 4534-2006 | |
| Commercial Quality | CS | DX51D+Z | SGCC | G1+Z |
| STRUCTURE STEEL | SS GRADE 230 | S220GD+Z | SGC340 | G250+Z |
| SS GRADE 255 | S250GD+Z | SGC400 | G330+Z | |
| SS GRADE 275 | S280GD+Z | SGC440 | G350+Z | |
| SS GRADE 340 | S320GD+Z | SGC490 | G450+Z | |
| SS GRADE 550 | S350GD+Z | SGC570 | G500+Z | |
| S550GD+Z | G550+Z | |||
PRODUCT DETAILS
| Commodity | Hot Dipped Galvanized Steel Coil,Galvanized Steel Coils, Gi Coil |
| Grade: | JIS G3302-94 Q195, Q235,Din17175 |
| SGCC, SGCH,SGC340 SGC400 SGC440 SGC490 SGC570 | |
| SGHC SGH340 SGH400 SGH440 SGH490 SGH540 | |
| DX51D DX52D DX53D DX54D | |
| S220GD S250GD S280GD S320GD S350GD S400GD S500GD S550GD | |
| Standard: | ISO,JIS,ASTM,AS EN |
| Zinc coated: | 30-275g/m2 |
| Surface treatment: | Chromated and oiled, and ant-ifinger |
| Hardness: | Softy , half hard and hard quality |
| Thickness: | 0.11-6.0mm |
| Width: | 30-2200mm |
| Supply Ability: | 10000MT/month |
| Coil weight: | 3-8MT/Coil or as your request |
| MOQ: | 5MT |
| Packaging: | Export standard, seaworthy |
| Substrate: | Cold rolled Substrate |
| ID: | 508mm or 610mm |
| Trade Term: | FOB, CFR, CIF |
| Payment terms: | T/T, L/C at sight,West Union |
| Delivery time: | 10-20days after confirmed order |
| Loading port: | Shanghai port |
| Container size: | 20ft GP:5898mm(Length)x2352mm(Width)x2393mm(High) |
| 40ft GP:12032mm(Length)x2352mm(Width)x2393mm(High) | |
| 40ft HC:12032mm(Length)x2352mm(Width)x2698mm(High) |
PRODUCT DISPLAY
| Name | GI steel coil | GL steel coil /Anti-Finger |
| Standard | GB/T-2518JIS G 3302EN 10142/10427ASTM A653 | GB/T-14798JIS G 3321EN 10215ASTM 792 |
| Grade | SGCCDX51D+Z | SGLCCDX51D+AZ |
| Thickness | 0.12-2.0mm (±0.02mm) | 0.16-0.7mm(±0.02mm) |
| Width | 30-1250mm (±2mm) | |
| Length | Coil or as Customers' requirement | |
| Zinc/Aluzinc coating | Zn 30g/sm-275g/sm | |
| Spangle | Mini/Regular/Big | Regular |
| Coil weight | 3-8tons or As your requirement | |
| Hardness | CQ/FH/As your requirement (G300-G550) | |
| Surface Treatment | Anti-Finger printing ,Chromated, oiled/ non-oiled | |
| Certification | ISO9001 | |
| Application | Structural use ,roofing, corrugated roofing, commercial use, household appliance, industry | |
EXHIBITION OF COOPERATION
CERTIFICATION
FAQ
Q:Can I get samples before order ?
A:Yes, of course. Usually our samples are free,we can produce by your samples or technical drawings.
Q:Can I go to your factory to visit?
A:Of course, we welcome customers from all over the world to visit our factory.
Q:What product information do I need to provide?
A:You need to provide the grade, width, thickness, coating and the number of tons you need to purchase.
Q:Does the product have quality inspection before loading?
A:Of course, all our products are strictly tested for quality before packaging, and unqualified products will be destroyed.we accept third party inspection.
Q:How do we trust your company?
A:We specialise in steel business for years, headquarter locates in Liaocheng, Shandong province, you are welcome to investigate in any ways, by all means, we have CE and ISO9001 certificate, quality can be guaranteed.Similar Video Recommendation
