An automatic sheet shearing machine is a machine that is used to cut sheet metal into smaller strips or coils. The cnc shearing machine is typically equipped with a set of circular cutting blades that are designed to shear the metal as it passes through the machine. The machine is also equipped with a series of rollers that help to guide the metal through the cutting process, ensuring that the cuts are straight and precise.The automatic shearing sheet metal slitting machine is typically used in industrial settings where large quantities of sheet metal need to be cut into smaller pieces. The machine is capable of cutting a wide range of metals, including steel, aluminum, and copper, and can handle sheet metal of varying thicknesses.It is used for steel wire processing machine,cement pole making machine and cage welding machine.
Technical Parameters
|
No. |
Name |
Technical Specification |
|
1 |
Input voltage |
AC440v± 5%, 60Hz, three-phase four wire system |
|
2 |
Cutting width range |
300mm |
|
3 |
Cutting length range |
1000 |
|
4 |
Cutting thickness range |
1.6-2.3mm |
|
5 |
Conveying speed |
6000mm/min |
|
6 |
Air source |
Max7.2kg∕cm² |
|
7 |
Motor power |
4Kw |
|
8 |
Machine weight |
1600Kw |
|
No. |
Name |
Description |
Remark |
|
1 |
Punching machine |
Provides cutting force |
Notes about rotation direction of motor running |
|
2 |
Material conveyor |
Conveys steel sheet after cutting |
|
|
3 |
Rolling machine |
Rolls the steel sheet after cutting |
|
|
4 |
Material Tray |
Holds bundles of steel sheet |
It is about 3m far away from punching machine |
