Product details


Discover the Ultimate Logistics Solution: High Speed Roll Up Doors

Are you looking to streamline your logistics operations and boost efficiency? Our High Speed Roll Up Doors are precisely engineered for logistics centers, warehouses, and distribution hubs that demand rapid access and superior performance. With a blend of cutting-edge technology and robust design, our doors set a new standard in the industry.

Key Features:

1. **Electric High Speed Door**: Powered for precision, these doors offer lightning-fast opening and closing, reducing wait times and enhancing workflow.

2. **Fast Roller Shutter Door**: Enjoy rapid response times without compromising on safety or durability. Ideal for high traffic areas requiring quick access.

3. **High Fast Rolling Door**: Designed for environments where space is at a premium, these doors rise swiftly to provide unimpeded entry and exit.

4. **High Speed Shutter Door**: Combines speed with protection, featuring auto-locking systems and weather-tight seals for secure operation in any climate.

Why Choose Our High Speed Roll Up Doors?

- **Time-Saving**: Optimize your logistics processes with doors that react instantly to your operational needs.
- **Safety & Security**: Built-in intelligent sensors prevent accidents and ensure your assets remain protected.
- **Energy Efficiency**: Insulated to reduce energy consumption and maintain indoor climate stability, leading to cost savings.
- **Customizable**: Tailored to your specific requirements – choose your preferred size, color, and additional features.
- **Low Maintenance**: Designed with longevity in mind, ensuring minimal upkeep and maximum reliability.
- **Integration Ready**: Seamless connectivity with smart building automation systems for advanced control and monitoring.

Take Your Logistics to the Next Level

Whether you're handling perishable goods, managing high-volume shipments, or operating in extreme weather conditions, our High Speed Roll Up Doors are designed to meet your most demanding logistics challenges head-on.

Upgrade your facility today with our state-of-the-art High Speed Roll Up Doors and experience the unparalleled combination of speed, security, and efficiency. For more information, get in touch with us now and revolutionize your logistics game!





High Speed Door
SPEEDEER high speed door, Equipped with Baojiu servo control system for intelligent operation, servo high-precision drive unit, with patented safety protection technology, with safe, stable, fast and efficient professional performance. Innovative visual man-machine interface design, man-machine communication, real-time display of running status and fault codes. At the same time, the concept of industrial aesthetics is introduced into the structural process design, combined with automatic laser fine cutting and precision components to create high-performance products.
Installation Site
Innovative technology
More functions

Various colors available
More Details


① The front box
② Motor
③ Fixed angle iron
④ Track
⑤ Aluminum profile wind-resistant ribs
⑥ Transparent window
⑦ Identification nameplate
⑧ Control box
⑨ PVC door curtain
⑩ Infrared safety photoelectric
⑪ U-shaped bottom edge






Installation Instructions
All measurements are made indoors and each value must be measured at at least three points:
H--the height of the doorway (the distance from the ground to the top of the doorway) B--the width of the door opening (the distance from the left edge of the door opening to the right edge) h--Above the doorway (the distance from the top of the doorway to the ceiling) is generally reserved 600mm b1/b2--The lateral distance of at least 200mm (the distance from the corresponding edge of the door opening to the obstacle) is required to have 500mm reserved on the side of the motor: When measuring H and B, take the maximum value as the final dimension When measuring h b1 b2, take the smallest value as the final size
Basic configuration
Technical parameter
Maximum size
5800*6000mm(W*H)



Wind pressure
6-8 wind (refer to the size of the door)



Opening speed
1.0-2.0 m/s (speed adjustable, refer to the size of the door)



Closing speed
0.8 m/s (speed adjustable)



Operating temperature
-5 to 60°C



PVC base cloth thickness
0.8-1.2mm



Base fabric color
Blue, gray, white and other colors are optional



Frame material
cold-rolled steel plate with paint, 304 stainless steel, aluminum alloy



Voltage
220V/50HZ



Interlock function
support



Linkage function
support (can provide door-open in-position, door-close in-position signal)



Induction mode
Radar, geomagnetic, photoelectric, rope, remote control



Safety protection
photoelectric (standard), safety bottom edge (optional)



Automatic three-dimensional warehouse outlet

Fast rolling shutter door + aluminum alloy rolling shutter door

Nongfu Spring Company Project

Air shower room transparent high speed door
