Main features:

The drum of the mixer can carry out two movements simultaneously, one is the rotation of the drum, the other is the swing of the drum with the swing frame. The call and material move with the drum in the drum. Flip and mix at the same time. Material can be fully mixed in a short time, the machine is suitable for all powder and granular material mixing

Working principle:

The two - dimensional mixer is mainly composed of drum, swing frame and frame. The drum is arranged on the swing frame, supported by four rollers and positioned axially by two retaining wheels. In the 4 supporting rollers, the rate of 2 driving wheels by the rotating power system to drive the rotation of the drum, the swing frame by a group of crank white bar mechanism to drive, crank swing bar frame mounted on the frame, swing frame supported by bearing components on the frame

Key parameter:

Model	Max fed capacity(kg/batch)	True motor(kw)	Sway motor(kw)	Size(mm)   A    B    C    D    M     H
EHY100	40	1.1	0.75	860        900       200      400     1000      1500
EHY300	78	1.1	0.75	1000     1100      200      580     1400       1650
EHY600	150	1.5	1.1	1300     1250      240      720     1800       1850
EHY800	200	1.5	1.1	1400     1350      240      810     1970       2100
EHY1000	350	2.2	1.5	1500     1390     240       850     2040       2150
EHY1500	550	3	1.5	1800     1550     240       980     2340       2280
EHY2000	750	3	2.2	2000     1670     240       1100   2540       2440
EHY2500	950	4	2.2	2200     1850     240       1160   2760       2600
EHY3000	1100	5	4	2400     1910     280       1220   2960       2640
EHY4000	1800	7.5	5	2700     2290     300       1440   3530       3000
EHY10000	3000	15	11	3200     2700      360      1800    4240       4000
EHY12000	4000	15	11	3400     2800      360      1910    4960       4200
EHY15000	5000	18.5	15	3500     3000      360       2100    5000      4400

Remarks:
1.Delivery:15 working days in factory
2.Payment:30% advance,70% before shipping by Paypal/TT

3.If u feel interested in this powder mixer or screw conveyor or sifting machine or spices powder grinding machine  or food drying machine  or capsule blister packing machine or capsule filling machine or capsule polishing machine or capsule counting machine or tablet press or packing machine etc someday that we produced u can tell me your specific requirement so that i can better recommend more suitable for your demands machine,what do u think
