Football Stadium LED Screen
2 year ago
Product Introdution
These LED screens are typically made up of thousands of individual LED modules that work together to create a seamless, high-resolution display. The screens are designed to be bright and visible even in bright sunlight, ensuring that all spectators can easily see the content on the screen.
The LED screen are controlled by a central system that allows operators to switch between different content sources, such as live camera feeds, pre-recorded videos, and graphics. This allows them to provide real-time information to the spectators, such as scores, statistics, and player profiles.
In addition to enhancing the spectator experience, LED screens in football stadiums are also used for advertising purposes. Advertisers can purchase advertising space on the screens and display their commercials or promotional content to a large audience.
Appication
An outdoor P5 football stadium advertising LED screen is a large electronic display board that is used to display advertisements, scores, and other information during football matches. The screen is made up of thousands of small LED lights that work together to create a high-resolution display that can be seen from a distance.
Packing Solution
Packing way: Wooden box
Data Sheet
|
MAIN TECHNICAL PARAMETERS FOR OUTDOOR LED DISPLAY(PITCH5) |
|||
|
（Technical parameters） |
UNIT |
（ parameters values ） |
|
|
（Pixel pitch） |
MM |
5 |
|
|
（Panel size） |
MM |
L320*H160*T14 |
|
|
（Physical density） |
/M2 |
40000 |
|
|
（Pixel configuration） |
R/G/B |
1,1,1 |
|
|
（Driving method） |
|
1/8 Constant current 1/8scan |
|
|
（LED Encapsulation） |
SMD |
1921 |
|
|
（Display resolution） |
DOTS |
64*32=2048 |
|
|
（Module weight） |
KG |
0.25 |
|
|
（Module port） |
|
HUB-HD75 (2) |
|
|
（Module working voltage） |
VDC |
5 |
|
|
（Module consumption ） |
W |
25 |
|
|
Panel Parameter |
|||
|
（Viewing angle） |
Deg. |
140 |
|
|
（Option distance） |
M |
4-30 |
|
|
（Driving device） |
|
IC:2037S/1065s |
|
|
（Every square metre module） |
PCS |
19.5 |
|
|
（Maximum power） |
W/ M2 |
490 |
|
|
（Frame Frequency） |
HZ/S |
≥60 |
|
|
（Refresh frequency） |
HZ/S |
≥1920/7680HZ |
|
|
（Equilibrium brightness） |
CD/ M2 |
≥5500-6500mcd |
|
|
（Working environment temperature） |
0C |
-10~60 |
|
|
（Working environment humidity） |
RH |
10%～70% |
|
|
（Display working voltage） |
VAC |
AC47~63HZ，220V±15%/110V±15% |
|
|
（Colour temperature） |
|
7000K-10000K |
|
|
（Gray scale/color） |
|
≥16.7M color |
|
|
（Input signal） |
|
RF\ S-Video\ RGB etc |
|
|
（Control system） |
|
NovaStar Linsn Coloright |
|
|
（Mean free error time） |
HOURS |
＞5000 |
|
|
（Life） |
HOURS |
100000 |
|
|
（Lamp failure frequency） |
|
＜0.0001 |
|
|
（Antijam） |
|
IEC801 |
|
|
（Safety） |
|
GB4793 |
|
|
（Resist the electricity） |
|
1500V last 1min No breakdown |
|
|
（IP rating） |
|
The back IP40，The front IP65 |
|
|
（Steel box size） |
mm |
L640*h640/960x960 |
|
