Dimension
L434*W154*H111mm
Weight:15kg
Two 7S2P module in series connected to 14S2P(48V100Ah)
253987642578
2 year ago
Beiamp New Energy Co., Ltd.
2 year
Product details
Product Description
Motive Power Battery-AGV Battery :INP27148101A-50Ah
This particular battery cell is a high-capacity lithium-ion battery with a capacity of 50 ampere-hours (Ah). It is specifically designed for electric vehicles (EV) and utilizes NCM (nickel-cobalt-manganese) chemistry, which offers excellent energy density and power output. The term "1C charge" refers to the charging rate at which the battery can safely accept current equal to its capacity, ensuring efficient charging without causing any damage. On the other hand, "3C discharge" indicates that this battery has the capability to deliver three times its capacity in terms of current during discharging, providing ample power for demanding applications.
With its impressive specifications and advanced technology, this 50Ah EV/NCM battery with 1C charge and 3C discharge capabilities combined with a VDA module represents an innovative solution for powering electric vehicles efficiently while maintaining reliability and longevity.
3.65V 50Ah NCM 3.65V 50Ah NCM
Specification
|
Item
|
Specification
|
Unit
|
Remark
|
|
Model
|
INP27148101A-50Ah
|
|
|
|
Type
|
Prismatic
|
|
|
|
Material
|
NCM
|
|
|
|
Nominal Voltage
|
3.65
|
V
|
|
|
Nominal Capacity
|
50
|
Ah
|
@ 25℃
|
|
Energy
|
182.5
|
Wh
|
|
|
Energy Density
|
206
|
Wh/kg
|
|
|
Charge Voltage
|
4.2
|
V
|
|
|
Discharge End Voltage
|
2.8
|
V
|
|
|
Standard Charge Current
|
25
|
A
|
0.5C
|
|
Max Continuous Charge Current
|
50
|
A
|
1C
|
|
Standard Discharge Current
|
50
|
A
|
1C
|
|
Max Continuous Discharge Current
|
150
|
A
|
3C
|
|
Peak Discharge Current
|
250
|
A
|
3S
|
|
Charge Temp. Range
|
0~50
|
℃
|
|
|
Discharge Temp. Range
|
-30~60
|
℃
|
|
|
Storage Temp. Range
|
-20~35
|
℃
|
|
|
Dimension
|
27*148*101
|
mm
|
|
|
Weight
|
885
|
g
|
|
|
Cycle life
|
1500
|
Cycles
|
@ 1C/1C(3.0~4.15V)
|
Packing & Delivery
7S2P module (24V100Ah)
