6 swing reducer
2 year ago
IE series planetary reducer is composed of multistage planetary transmission. It has the characteristics of small radial size, modular design, large output torque, various output shaft forms, high transmission efficiency, low noise, and good economy. Therefore, it is widely used in construction engineering, railway, highway, ship, petroleum, coal mine, metallurgy and other machinery. According to different needs, users can choose different types of hydraulic motors or motors as driving components. 3, Model example IE613-N110IAR indicates that the maximum radial size of the planetary reducer is 610mm, and the three-stage planetary transmission is adopted
2. Model description
3. Model examples
IE613-N110IAR indicates that the maximum radial size of the planetary reducer is 610mm, the use of 3-stage planetary transmission, with a brake, the reduction ratio is 110, the output shaft is in the form of an involute spline, and the radial hydraulic motor.
4. Technical description
1) The reducer can be accompanied by a hydraulic static brake;
2) The selection of the reducer should consider the requirements of safety factor grade, FEM grade and service life;
3) This type of reducer is not suitable for bearing large radial load, generally only used to transfer torque, installation and operation must check whether the output shaft is compressed and bent;
4) The choice of lubricating oil for the reducer must be selected according to the environment and working temperature of the reducer. The reducer must be replaced once after 150-200 hours of trial operation, and then according to the working condition of the gearbox, the oil must be changed after 2000-4000 hours of operation, and it must be replaced at least once a year. When changing the oil, in order to facilitate the emptying of the lubricating oil in the reducer, it is recommended that the lubricating oil be replaced when it is warm;
5) The recommended operating temperature of the standard reducer is -15℃- +40℃.
Application
Mining machinery:coal mine drill, heavy duty handling car
Construction machinery:scavenging machine, aircraft tractor
Farming machinery: mini farming vehicle, ditcher
