Product details

CNC Slitting Automatic Lathe SL205



  • CNCl Auto Lathe Machine control system. Taiwan (new generation) system, double channel control, high efficiency, high precision. · High precision spindle. The machine tool spindle adopts NSK(Japan) ultra-high precision angular contact ball bearing to ensure the high rigidity and durable accuracy of the spindle. The spindle runout is less than 2μm.
  • High Automatic Turning Machine rigidity. Structure design is stable, high quality tightly baked cast iron bed, after aging treatment, high rigidity.
  • High precision feed. The feed shaft is fully servo driven. NSK(Japan) high-precision lead screw bearing and Shang Yin/Intime (Taiwan) high-precision lead screw guide rail are adopted to ensure the machining accuracy and long-term accuracy maintenance. The repeated positioning accuracy of each feed shaft is less than 3um.
  • Guide sleeve construction. Can choose no guide sleeve, fixed guide sleeve and rotating guide sleeve cutting mode, to meet the diversified processing requirements.
  • Cnc Auto Lathe Tool system. Adopt the layout structure of row cutter, smooth chip discharge and compact structure. By configuring the side power tool and spindle indexing function, it can meet the complex machining needs of turning, milling and drilling.
  • Lubrication system. All lead screw and guide rails are lubricated by centralized lubrication system to ensure the long-term and efficient operation of machine tools.
  • Automation. Through the configuration of automatic feeder, automatic continuous processing can be realized.
  • The application. Widely used in communication, electronics, automotive, pneumatic and hydraulic, medical, instrumentation, aviation and other industries of complex, small, precision, slender shaft parts processing.





205 1 Jpg



Specification:

SL205 SPECIFICATIONS Parameter UNIT
1 Rod Hole Diameter Φ25 mm
2 The Largest Processing Bar Diameter Φ20 mm
3 Maximum Length of Machining Parts 50/180/220 mm
4 Highest Spindle Speed 8000 r/min
5 The Spindle Power 4.2 kW
6 Maximum Speed of the Back Shaft 8000 r/min
7 Back Shaft Power 3.1 kW
8 Dividing of Principal Axis C-axis function Continuous indexing
9 The Biggest End Face Hole Diameter Φ10 mm
10 The Biggest End Face M8 mm
11 Cylindrical Turning Tool 12*12 mm
12 Cylindrical Turning Tool 6 6 the
13 Axial Machining Tool 4  (ER16) /
14 Minimum Resolution 0.001 mm
15 Fast Moving Speed X/Y/Z axis : 24 m/min
16 Cooling Motor Power 0.4 kW
17 Machine Tool Overall Dimensions (length x width x height) 2300×1300×1770 mm
18 Machine Weight 2400 kg




Main parts brand:

ITEM BRAND
CNC Controller TAIWAN-SYNTEC
Servo Electro-spindle TAIWAN
Servo Motor&driver TAIWAN-SYNTEC
Spindle Encoder TAIWAN-SYNTEC
Spindle Bearing JAPAN-NSKP4 class
Ball Screw Bearing JAPAN-NSK
Ball Screw TAIWAN-HIWIN
Linear Guideway TAIWAN-HIWIN
Lubrication System JAPAN-HERG
Main Electricity Parts FRANCE-SCHNEIDER
Pneumatic Parts TAWAN-AIRTAC
Lock Nuts TAIWAN-YINSH
Shaft Coupling GERMANY-KTR




Optional Configuration:
- High Pressure Coolant System
- Oil Mist Collection System
- Angular Live Tool
- Automatic Chip Conveyor
- Automatic Bar Feeder
