Product details

Heat shrink wrap around sleeves consists low pre-heated special rubber adhesive and thick-wall irradiated cross linked polyolefin. When heated the backing layer shrinks and the adhesive flows and forms a reliable corrosion protection seal onto metal and adjacent coating surfaces.It installed by wrapping the tape on the pipe joints ,fittings ,bends ,elbows etc .After the shrinking of the tape ,the closure patch should be installed onto the overlap of the tape. it suitable for pipe operating temperature, 60 ℃，80 ℃ and more high temperature.This heat shrinkable materials have other products too, such as 3 LPE Heat shrink sleeves, 2 PE heat shrink tape, 3 LPP wrap around sleeve, HDD heat shrink wrap sleeves , shrinkable tape closure patch and so on.

Features:

Excellent resistance to cathodic disbondment.

Long term corrosion protection.

Non hardening and non cracking.

Fast application and high performance.

Excellent chemical resistance

Excellent resistance to shear forces

Mechanical protection and moisture resistance.

Item	Typical Value	Typical Value	Test Method
	HST 60	HST 80	-
Operating Temperature	Up to 60℃	Up to 80℃	-
Backing
Tensile Strength	23.20 MPA	23.50 MPA	ASTM D-638
Elongation at Break	650%	600%	ASTM D-638
Hardness, Shore D	50	52	ASTM D-2240
Dielectric Strength	32 Kv/mm	32 Kv/mm	ASTM D-149
Water Absorption	＜0.1%	＜0.1%	ASTM D-570
Volume Resistivity	2.5 x 10¹⁸ ohm.cm	2.5 x 10¹⁸ohm.cm	ASTM D-257
Adhesive
Item	Typical Value	Typical Value	Test Method
	HST 60	HST 80
Softening Point	90℃	121℃	ASTM E-28
Lap Shear	2.3MPA @23℃	3.5 MPA @23℃	ISO 21809
Installed Sleeve
Item	Typical Value	Typical Value	Test Method
	HST 60	HST 80
Peel to Steel	145N/cm@23℃	160N/cm@23℃	ASTM D 1000
Cathodic Disbondment	＜15 mm rad@23℃	＜15 mm rad@23℃	DIN EN 12068
Impact Resistance	＞ 15 J	＞ 15 J	DIN EN 12068
Indentation Resistance	＞1.0 mm@65℃	＞1.0 mm@65℃	DIN EN 12068
Thickness Range	1.5 mm to 2.9 mm
Width Range	150 mm to 600 mm

petro pipe shrink sleeves heat shrink tape
