The AC 5-axis waterjet cutter stands as a pioneering breakthrough in waterjet cutting technology, distinguishing itself from the Gantry Type Waterjet Cutting Machine through its distinctive cantilever structure. Departing from the constraints of traditional methods confined to vertical or slight-angle cuts, this five-axis waterjet system transcends those limitations. By integrating two servo rotating axes, it facilitates smooth and unhindered directional cutting. Enhancing the conventional three-axis setup, the AC 5-axis waterjet cutting head incorporates the A-axis (rotation around the X-axis) and the C-axis (rotation around the Z-axis), allowing significant angle deflection.

Leveraging the AC-axis structure and its adaptable angles, the AC 5-axis waterjet cutter excels in achieving extensive bevel stereoscopic cutting.
By anchoring the cutting point at the intersection of the AC-axis, it ensures unwavering coordinates during the AC-axis rotation.
Swift adaptations of the five-axis head facilitate seamless corner transitions, ensuring uninterrupted directional shifts.
The cutting bevel angles can reach up to plus or minus 45°, significantly broadening the scope of cutting versatility.
