cementing head
Main parts are made from AISI4145H alloy steel.
Quick-latch adapter is designed to offer easier, faster and safer makeup for two-stage cementing.
It is manufactured utilizing API grade steels with API threads.
Positive lever indicates plug releasing.
Balance pipe is developed.Cementing Head Single Plug Type-Puyang Zhongshi Group Co.,Ltd
Technical Parameters
|
Size, mm Specifications, (in) |
Φ139.7 (5 1/2") |
Φ168 (6 5/6") |
Φ177.8 (7") |
Φ194 (7 5/6") |
Φ244.5 (9 5/8") |
Φ273 (10 3/4") |
Φ339.7 (13 3/8") |
|
Overall Length, mm |
1460 |
1500 |
1500 |
1550 |
1750 |
1750 |
1780 |
|
Manifold |
2"Union |
||||||
|
I.D. of Plug Container, mm |
Φ125 |
Φ150 |
Φ160 |
Φ175 |
Φ225 |
Φ250 |
Φ320 |
|
Length of Plug Container, mm |
400 |
450 |
450 |
450 |
550 |
550 |
600 |
|
Working Pressure, MPa |
35,50 |
35,50 |
35,50 |
35,50 |
35,50 |
35 |
35
|
Puyang Zhongshi Group Co., Ltd. is a member of Sinopec Corporation. As a national high-tech enterprise and scientific enterprise, we launch business in areas of science & technology, industry, and trade.Our products have attained ISO9000 quality system certification. Some petroleum product machinery have passed the evaluation of API certification in the United States.
Cementing Accessories, Casing Centralizer, Pressure Vessels, Cementing Tool, Pumping Units, Centralizers, Accessories, Sucker Rod
