Product Introduction
32 Inch 2k High Tni(110℃)2500nits LCD Panel
| Panel Brand | RISINGSTAR | Panel Model | RS320ENT-GD25 |
| Panel Size | 32″ | Panel Type | a-Si TFT-LCD |
| Resolution | 1920(RGB)×1080 | Pixel Format | RGB Vertical Stripe |
| Display Area | 698.4(W)×392.9(H) mm | Bezel Opening | / |
| Outline Size | 725.2 (W)×422.7(H)×14.4(D) mm | Surface | Antiglare (Haze 3%), Hard coating (2H) |
| Brightness | 2500 cd/m²or customized | Contrast Ratio | 1200:1 (Typ.) (TM) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) | Display Mode | AMVA3, Normally Black, Transmissive |
| Display Colors | 16.7M | Response Time | 6 (Typ.)(G to G) |
| Frequency | 60Hz | Input Voltage | 12V (Typ.) |
| Touch | Tangible | Signal Interface | LVDS (2 ch, 8-bit) , 30 pins Connector |
| Environment | Operating Temp.: 20°C~ 85 °C ; Storage Temp.: -25 ~ 95°C | ||
32-inch touchable LCD display usually used as the control panel in workshop of factory, this digital control panel can display information clearly and workers can intreact it on the screen directly to decreasing the misoperation.
All the LCD module can be customize by your request!
