Chnki Quilting Sewing Machine Operation

1、360° infinite rotation of the machine head for fast sewing speed; the diameter of the machine head is only 20cm, with a full encirclement structure, the operator's safety is guaranteed and it enables the operator to work at close range. With head lift technology: the head automatically rises at the end of sewing and changes to another template (requiring manual adjustment by the operator), saving time for secondary manual adjustment; the pressing device automatically rises and falls.

2、Digital precision high-speed sewing machine with three-dimensional movement. The system controls the synchronized rotation of the machine head and the bobbin bed seat rotary shuttle, creating identical stitches for both the downstitch and backstitch, achieving the ideal perfect stitch and improving the quality of the sewn object.

3、Because there is no reverse seam, there is no excessive air shift, so you can start sewing close to the sewing machine and increase efficiency by 30% (efficiency varies with different patterns), and always maintain the smooth peak, avoiding inconsistent stitching, thread breakage and unstable thread cutting caused by reverse seam. Locking stitch, sewing more firmly.

4、Precision guide rack: precise sewing with little wear; X-axis and Y-axis are driven by rack.

5、max sewing speed: 3000rpm.

6、The whole machine has 11 motors (9 for the production table and 2 for the preparation table)

Production table: 2 servo motors (Panasonic): upper spindle and lower spindle

                                 7 stepper motors: X-axis (2), Y-axis (2), middle presser foot, upper and lower rotation axis

   Preparation table: 2 stepper motors

7、The sewing area is Y2500mm*X2600mm, and the sewing area can be customized according to the customer's requirements; the sewing area can be 1222, 1424, 1626, 1828, 2124, 2342, 2526, 2542, 2826.

8、The 360° head rotating needle can be used for 7# needle at least, which can effectively reduce the running down phenomenon.

9、clip material needs to be carried out manually, home textiles with clips better, laser curtain with air pressure frame better. This machine is best to do laser curtain. Can also make water filter (environmental protection).

10、2 times the thread volume of large rotary shuttle (Hirose), reduce the frequency of shuttle change and improve production efficiency.

11、 high precision design, high precision, shift frame on the cloth, so it can reduce the phenomenon of broken needles or broken thread, the thread loop is stable and beautiful, can adapt to thick and thin materials.

12、Flexible programmable middle presser foot: according to different fabric thickness, the height of the middle presser foot can be adjusted at any time to adapt to a variety of sewing scenarios.

13、Automatic thread cutting device (thread cutting is by electromagnet): save manpower thread is shorter and reduce the second manual thread cutting.

14、The electric control box uses the new Ruiyang system.

15、the height of the machine can be adjusted, to be adjusted in the system of the touch screen.

16、15'' LCD operation panel, touchable operation is more convenient.

17、Imported pneumatic components: improve the precision of the machine, accurate sewing.

18、Optional automatic bobbin changer and BOSTER electronic automatic bobbin winder (now the machine is equipped) → the black pile under the machine.

 This is an apparel equipment, can be used for a variety of clothing sewing machine, is also for the garment factory of industrial sewing machine, the face of rising labor costs this automatic sewing machine also conforms to the development of the times. Customizable sewing machines according to customer's needs.
