pole mould 9m

2 year ago
17 0
Product details

A concrete pole mould is a specialized tool used in the construction industry to create concrete poles. It is typically made of steel or other durable materials and is designed to shape and hold wet concrete in the desired shape and size of the pole.
The pole mould consists of two or more parts that can be assembled and disassembled to allow for easy removal of the cured concrete pole. It is typically lined with a release agent to prevent the concrete from sticking to the mould.
The pole molds are filled with wet concrete and then vibrated or compacted to remove air bubbles and ensure even distribution of the concrete. Once the concrete has cured and hardened, the mould is removed, leaving behind a solid concrete pole.
Concrete pole mold can be customized to create poles of various shapes and sizes, depending on the specific needs of the construction project. They are commonly used in the construction of utility poles, street light poles, and other structural poles.

Products Description
Inside Diameter(mm)
Wheel Distance(mm)
Wheel Diameter (mm)
Length(m)
Ø100
2000
Ø600
6-7
Ø110
2000
Ø600
6-7
Ø120
2000
Ø600
6-8
Ø130
2000
Ø600
6-8
Ø150
2000
Ø600
6-10
Ø170
2000
Ø600
6-12
Ø190
2000
Ø600
7-12
Ø190
2000
Ø650
15-18
Ø230
2000
Ø650
6-9
Ø310
2000
Ø650
6-9
Ø350
2000
Ø680
6-9
Ø390
2000
Ø750
6-9
Prestressed circle spun concrete pole moulds is used for concrete pole making. Its mainly manufacture technology is longitudinal tension by steel wires. Then it can squeeze out the excess water in the concrete under the centrifugal force. Thus, it can greatly improve the concrete density and strength.
In order to form concrete more quickly to meet the design strength of more than 70%, steam curing can be carried out so as to shorten the mould-releasing cycle.
Product Advantages
1. Saving a great deal of steel, about 30~70% (employing cold drawn steel wire can save 30%~60%; employing high stress steel wire can save 40%~69%).
2. Crack resistance can increase about 3~5 times.
3. Rigidity increases 1~3 times.
4. Reducing the cost (using cold drawn steel wire can reduce 25%~40%; using high stress steel wire can reduce 12%~21%).
5. Good durability, can delay the existence and expansion of cracks.
6. Protect the environment on which human beings depend on for existence, and reduce the deforestation.
