Surge Arrester for Distribusion Line

 24KV 5KA 10KA Composite Metal Oxide Polymeric Surge Arrester

Type	Rated voltage(kV)	Continuous operating voltage(kV)	Residual voltage(kV)					2ms rectangular current impulse withstand(A)	High current impulse of 4/10μS(kA)	Line discharge class
			8/20μS lightning current impulse		1/10μS steep current		30/60μS switching current impulse
YH10W-3	3	2.55	9		9.5		7.7	250	100	1
YH10W-6	6	5.1	18		19		15.4	250	100	1
YH10W-9	9	7.65	27		28.5		23.1	250	100	1
YH10W-12	12	10.2	36		38		30.8	250	100	1
YH10W-15	15	12.7	45		47.5		38.5	250	100	1
YH10W-18	18	15.3	54		57		46.2	250	100	1
YH10W-21	21	17	63		66.5		53.9	250	100	1
YH10W-21	24	19.2	72		76		61.6	250	100	1
YH10W-27	27	21.9	81		85.8		69.3	250	100	1
YH10W-30	30	24.4	90		95		76.5	250	100	1
YH10W-33	33	26.8	99		104.5		84.7	250	100	1
YH10W-36	36	29	108		114		92.4	250	100	1

Characteristics

1).Silicone rubber & Zinc oxide.

2).Excellent antifouling performance.

3).Good acid and alkalis resistance.

4).Each Surge Arrester is tested before shipment.

5).IEC standard.

6).ISO9001 and ISO14001 manufacturer.
