Crusher Hammer1.8 sandvik
2 year ago
Advantage of cemented carbide bar:
1. Perfect performance
2. Stable quality
3. 100% virgin raw material
4. various size accroding to your demand
5. Fast delivery
Application:
Rotor Tip set is equipped with tungsten carbide tip that protects the rotor of the VSI crusher against wear, mainly used for break stone or into sand, they are widely used in the field of cement, mining etc.
Reference sizes
| Length of the crusher hammer(mm) |
192 142 92 |
220 | 210 | 189 | 189 |
| Carbide plate size(mm) |
192*10*8 192*13*8 142*10*8 142*13*8 |
220*27*13 220*27*15 |
210*25*15*10 218*23*18*8.5 |
189*27*13 | 189*27*13 |
→less replacement of crushing hammer&high efficient working
→excellent wear & shock resistance
| Grade | Properties | Application | ||
| Density (g/cm3) | Toughness(HRA) | TRS(n/mm2) | ||
| ZT1 | 14.90-15.10 | 91.1 | 2400 | excellent wear resistance & hardness for crushing granite, quartz porphyry, siliceous rock, iron ore.etc. |
| ZT2 | 14.70-14.85 | 90.0 | 2700 | excellent wear resistance & hardness for crushing limestone, sand stone, areaceous shale, lean iron ore, cupriferous pyrite, etc. |
| ZT3 | 14.60-14.80 | 89.5 | 2500 | excellent wear resistance and hardness for crushing granite, amphibolite, siliceous rock, cupriferous pyrite, marble, sandstone, gray stone etc. |
| ZT4 | 14.60-14.80 | 88.5 | 2300 | general wear resistance and hardness for crushing metasandstone, quartz porphyry, granite, ordinary limestone, granite in strip mine, dolomite, magnetic iron ore etc. |
| ZT5 | 14.20-14.40 | 87.0 | 2800 | high hardness and a bit low wear resistance for crushing sandstone, hard rock, quartz rock, dolomite, iron ore, dorite, granite, sandstone etc. |
| ZT6 | 14.00-14.60 | 85 | 1900 |
crushing soft shale, limestone, coal, harden clay etc. |
