Micro metal mesh EMI film

12 month ago

40 0 

5 year

Product details

150 mesh copper grid pet film,with adhesive, can be directly sticked to existed glass/touch screen, used for EMI shielding, anti radiation, to keep information safety.

TECHNICAL DATA SHEET

*Physical property parameters*
item			unit	Performance Index	Detection Method	Remark
item			unit	EMI-150	Detection Method	Remark
Thickness	Protective film		μm	50～60	ASTM D374	Optional
	First layer			metal mesh layer
	Substrate		μm	125+5		Material:PET
	Ahesive					Available
Mesh shape				45°
Mesh width			μm	17
Mesh spacing			μm	143
Visible light transmittance			%	≥75	GB/T 2410-2008
Surface resistance (conductive side)			ohm	≤0.09	Four probe surface resistance tester
Adhesion (conductive side)				At least reach two-grade	GB/T 9286-1998
Adhesive peel strength			g/25mm	≥100	GB/T 2792-1998	For glass panel
Wet-heat resistant property		Resistance variation	%	≤30	65℃、90% 100hours	ΔR/R0
Wet-heat resistant property		Light transmittance change	%	≤5	65℃、90% 100hours	ΔT/T0

SHIELDING EFFECT

Main performance

Model

Transmittance

Frequency(DB)

14K

100K

10M

30M

150M

450M

950M

10G

EMI-150（150Mesh）

>75%

APPLICATION

1_medical 2_medical

3_medical 4_medical

All METAL MESH PET FILM products have stable resistance, very small tolerance, with super high transmittance 80%.

Deposited conductive coatings are very thin and are easily scratched or cracked if handled improperly. When removing film from a roll, care should be taken not to bend or crease it. It is important never to allow the conductive side to come in contact with a surface, such as a table, during processing operations.

When ordering rolls of film, please correctly specify film width, length of film on each roll and number of rolls desired. Rolls are supplied on 3 inch cores depends on your requirements.

COMPANY INTRODUCTION

CANTON FAIR SHOW

Ito Film 16 Ito Pet Film 1 2

Moire fringes can be completely avoided without adjusting the angle of the anti-glare shielding film, the conductive surface is blackened, and the performance is stable!

Other items choices: 85 opi MT85 EMI film with adhesive, Irregular micro mesh EMI film 160 OPI and 250 OPI totally no moire wave on LCD. 5 ohm and 10 ohm ITO PET FILM for EMI shielding etc.
