Classes 1-3 are typically divided into non-magnetic and magnetic compositions, while Class 4 is typically offered in magnetic compositions only. In addition to ASTM, Elmet offers "modified Class 2" compositions, which are 93% tungsten (W) by weight (wt%) and have some enhanced properties for certain defense applications.
We can also supply Nickel Alloys, Tungsten Alloy, Molybdenum Alloy in any form.
STANDARD GRADES
| Grade | ET90 | ET90NM | ET92.5 | ET92.5NM | ET93 | ET95 | ET95NM | ET97 |
| ASTM B-777 | Class 1 | Class 1 | Class 2 | Class 2 | – | Class 3 | Class 3 | Class 4 |
| AMS 7725E | Class 1 Type 2 |
Class 1 Type 1 |
Class 2 Type 2 |
Class 2 Type 1 |
– | Class 3 Type 2 |
Class 3 Type 1 |
Class 4 Type 2 |
| MIL-T-21014D | Class 1 | Class 1 | Class 2 | Class 2 | – | Class 3 | Class 3 | Class 4 |
| W content, wt.% | 90 | 90 | 92.5 | 92.5 | 93 | 95 | 95 | 97 |
| Ni content, wt.% | 7.0 | 8.9 | 5.3 | 6.7 | 5.6 | 3.5 | 4.4 | 2.1 |
| Fe content, wt.% | 3.0 | 1.1 | 2.2 | 0.8 | 1.4 | 1.5 | 0.6 | 0.9 |
| Density, g/cm3 | 17.0 | 17.0 | 17.5 | 17.5 | 17.7 | 18.0 | 18.0 | 18.5 |
| UTS, ksi | ≥ 110 | ≥ 110 | ≥ 110 | ≥ 110 | ≥ 110 | ≥ 105 | ≥ 105 | ≥ 100 |
| UTS, MPa | ≥ 758 | ≥ 758 | ≥ 758 | ≥ 758 | ≥ 758 | ≥ 724 | ≥ 724 | ≥ 689 |
| YS, ksi | ≥ 75 | ≥ 75 | ≥ 75 | ≥ 75 | ≥ 75 | ≥ 75 | ≥ 75 | ≥ 75 |
| YS, MPa | ≥ 648 | ≥ 648 | ≥ 648 | ≥ 648 | ≥ 648 | ≥ 648 | ≥ 648 | ≥ 648 |
| Elongation, % | ≥ 5 | ≥ 5 | ≥ 5 | ≥ 5 | ≥ 5 | ≥ 3 | ≥ 3 | ≥ 2 |
| Hardness, HRC | ≤ 32 | ≤ 32 | ≤ 33 | ≤ 33 | ≤ 33 | ≤ 34 | ≤ 34 | ≤ 35 |
| Mag. perm. | > 1.05 | ≤ 1.05 | > 1.05 | ≤ 1.05 | > 1.05 | > 1.05 | ≤ 1.05 |
> 1.05 |
Established in 2008, the company has grown over the years to become a leading manufacturer and supplier of metal products to a wide range of industries. The company continuously invests in research and development to improve product quality and durability. The company places great emphasis on customer satisfaction and is known for providing high quality products and excellent customer service. Today, the company has a global presence and serves customers in countries all over the world.
