5x5 inch-100g Grid cloth
2 year ago
In the current construction market, the use of Fiber Glass mesh can be seen everywhere. Usually fiberglass mesh is used in the insulation system of building exterior walls. Fiberglass mesh is used as an exterior wall Insulation mesh cloth, a supporting component of the exterior wall exterior insulation system, plays a role in improving the mechanical properties and crack resistance of the system's protective layer.
Fiberglass mesh cloth is based on fiberglass woven fabric and soaked in polymer anti-emulsion coating. As a result, it has good alkali resistance, flexibility and high tensile strength in the longitudinal and latitudinal directions, and can be widely used for thermal insulation, Anti Corrosion, waterproofing, fire protection, crack resistance, etc. of the interior and exterior walls of buildings.
In addition to exterior wall insulation systems, fiberglass cloth is also used in: gypsum boards, Roman columns, flues, etc. Granite, mosaic special mesh, marble back-mesh. Asphalt roof waterproofing, waterproof membrane fabrics, rubber product skeleton materials, reinforced plastics, fireproof boards, grinding wheel base fabrics, geogrids for highway pavements, caulking tapes for construction, etc. Alkali-resistant fiberglass mesh cloth is also used in ground engineering to prevent cracking. The application of fiberglass mesh cloth can be said to be quite extensive.
TECHNICAL DATA
| Type | Mesh size | Mesh size | Weight | Glue content |
Tensile Strength
N/5 cm
|
Weave |
Break Extend Rate |
| mm | mesh/inch | g/m² | Warp × Weft | Warp,Weft | |||
| CNP4*5-100-160G | 4 × 5 | 6 × 5 | 160 | 14.50% | 1730×1850 | Twist (Plain) | 3.6 - 3.8 |
| CNP5*5-100-80G | 5 × 5 | 5 × 5 | 80 | 14.50% | 670×780 | Twist (Plain) | 3.6 - 3.8 |
| CNP5*5-100-100G | 5 × 5 | 5 × 5 | 100 | 14.50% | 860×1050 | Twist (Plain) | 3.6 - 3.8 |
| CNP5*5-100-125G | 5 × 5 | 5 × 5 | 125 | 14.50% | 950×1260 | Twist (Plain) | 3.6 - 3.8 |
| CNP5*5-100-145G | 5 × 5 | 5 × 5 | 145 | 14.50% | 1350×1540 | Twist (Plain) | 3.6 - 3.8 |
| CNP6*6-100-240G | 6 × 6 | 4× 4 | 240 | 14.50% | 2600×2750 | Twist (Plain) | 3.6 - 3.8 |
| CNP6*6-100-300G | 6 × 6 | 4× 4 | 300 | 14.50% | 2940×3460 | Twist (Plain) | 3.6 - 3.8 |
| Others:Accept customization,Color:White,Yellow,Blue,Black,Red,etc. | |||||||
SPECIFICATION
Standing Packing
Supply Capacity
| Quantity(square meters) | 1-1000 | 1001-5000 | ＞5000 |
| Lead Time(days) | 3 | 5 | To be negotiated |
| Category | Fiberglass mesh | PVC Profile | Self-adhesive mesh |
| Daily capacity | 100,000m² | 250,000m | 30000m² |
