500 kg/h film washing line
4 year ago
PP PE Film Bags Washing Machine mainly used to process soft plastics such as plastic bags and plastic films. In addition, it can also handle PP PE hard plastics.Including crushers, feeders,dewater, rinsing tanks, Double Shaft Shredder and other machines.
1.1 Material characteristics
The material to be treated is PP PE film with contamination of:
● Labels
● Residues of original film content
● Metal, dust or sand accumulated during transportation or permanence in air
The materials can be in bales or loose, the operators should open the bale before introducing material into the line.
Finished product: clean PP PE flakes.
Next stage:PE PP Film Bags Pelletizing Machine.
In addition, our factory has other Plastic Recycling Machine.
1.1 Raw material & Final product:
|
Raw material & formulation |
Waste PP woven bag and PP jumbo bag and PE film..etc |
|
Final product & Output capacity |
Input capacity : around 600-700kg/hour Clean dry PP scraps :500kg/h |
|
Description of final product |
Scrap size: 10-12mm |
1.2 Work condition
|
Warehouse/Workshop
|
Dimension (M*M*M): 35(L)×5(W)×4.5(H); Crane: Machine positioning(provide by customer) |
|
Power supply & Installation power |
3-phase, 380V, 50 Hz; |
|
Wire/cables(provide by customer) |
Wires/cables from power supply to control cabinet of this production line; all electrical cables from control cabinet to each machine. |
|
Water supply hose/pipe(provide by customer) |
Water supply to machines and pools |
1.3 Energy consumption
|
Installation power |
Max 200KW (Actual power consumption percentage: 70-80%) |
|
Water supply |
Consumption: about 5 ton/h, can be recycled use, Water pressure: 0.4Mpa |
|
Manpower |
3-5 Persons (1-2 persons for feeding, 1-2 persons for collecting the finished PP scraps,1 person(skilled) for controlling the cabinet) |
