auto parts die casting mold

Weifang Yida Mold Co., Ltd. provides various mold customization services, Punching Mould， Deep Drawing Mould，Bucket Mould,Metal Parts， Please contact us

A deep drawing making machine production line typically consists of several machines and processes that work together to produce deep drawn parts. Here is a general outline of the production line:

1. Coil unwinding: The production line starts with the unwinding of metal coils, which are typically made of steel or aluminum. The coils are loaded onto a decoiler machine that feeds the material into the next process.

2. Cleaning and lubrication: The metal coils may go through a cleaning process to remove any dirt or debris. They are then lubricated to reduce friction during the deep drawing process.

3. Feeding and blanking: The metal coils are fed into a feeding machine, which cuts them into individual blanks of the desired size. The blanks are then transferred to the deep drawing machine.

4. Deep drawing: The deep drawing machine is the central component of the production line. It uses a combination of hydraulic or mechanical force to draw the blank into a die, creating the desired shape. The deep drawing machine may have multiple stages to gradually form the part.

5. Trimming and piercing: After the deep drawing process, the formed parts may undergo trimming and piercing operations to remove excess material and create holes or slots as required.

6. Quality control: Throughout the production line, quality control measures are taken to ensure the parts meet the required specifications. This may include visual inspections, dimensional checks, and material testing.

7. Finishing and packaging: Once the parts pass the quality control checks, they may undergo additional finishing processes such as cleaning, deburring, or surface treatment. Finally, the parts are packaged and prepared for shipment or further assembly.
