7 10 13 Inch Night Vision FPV Racing Drones
9 month ago
Product details
I hope this Night Vision FPV Racing Drones can bring you passion and happiness. Please do not use it for war
This Night Vision FPV Racing Drones can be customized in different sizes according to customer needs, including 7, 8, 9, 10, and 13 inches.
It can carry 2.5-10 kilograms according to customer load requirements and has a remote control distance of 3-8 kilometers.
Therefore, the price needs to be discussed.
7 Inch Night Vision FPV Racing Drones Products Description
This Night Vision FPV Racing Drones can be customized in different sizes according to customer needs, including 7, 8, 9, 10, and 13 inches.
It can carry 2.5-10 kilograms according to customer load requirements and has a remote control distance of 3-8 kilometers.
Therefore, the price needs to be discussed.
7 Inch Night Vision FPV Racing Drones Products Description
1. Frame- 7Inch Carbon Fiber Frame
2. Stack-FC BL F405 ESC F60 Blheli-S 60A -6S
3. DroView 5.8G Reaper Extrme 2.5W 40CH
VTX /1.3G 1.6W VTX
4. DroView 1/3 CMOS 1500TVL Camera
5. DroView 2807 1300KV MOTOR
6. HQProp 7X4X3 7Inch 3-blade PC Props
7.Happymodel 915MHz RX ELRS
8.VTX Antenna 5.8G/1.3G RHCP 150MM
9. Battery Strap 20*300mm*2
9 Inch Night Vision FPV Racing Drones Products Description
1. Frame-DroView 10Inch Carbon Fiber Frame
2. Stack-F405 MK2 V2 F55 Blheli-S 55A -6S
3. DroView 5.8G Reaper Extrme 2.5W 40CH VTX /1.3G 1.6W VTX
4. DroView 1/3 CMOS 1500TVL Camera
5. DroView 3115 700KV MOTOR
6. German 1050Prop (2PAIRS)
7. Happymodel 915MHz RX ELRS
8.VTX Antenna 5.8G/1.3G RHCP 150MM
9. Battery Strap 20*300mm*2
13Inch Night Vision FPV Racing Drones Products Description
1. Frame-DroView13 Inch Carbon Fiber Frame
2. Stack-F405 Blheli-S 80A -8S
3. DroView15.8G Reaper Extrme 2.5W 40CH VTX /1.3G 1.6W VTX
4. DroView1 1/3 CMOS 1800TVL Camera
5. DroView1 4214 660KV MOTOR
6. German 13 inches (2PAIRS)
7. Happymodel 915MHz RX ELRS
8.VTX Antenna 5.8G/1.3G RHCP 150MM
9. Battery Strap 20*400mm*2
2. Stack-FC BL F405 ESC F60 Blheli-S 60A -6S
3. DroView 5.8G Reaper Extrme 2.5W 40CH
VTX /1.3G 1.6W VTX
4. DroView 1/3 CMOS 1500TVL Camera
5. DroView 2807 1300KV MOTOR
6. HQProp 7X4X3 7Inch 3-blade PC Props
7.Happymodel 915MHz RX ELRS
8.VTX Antenna 5.8G/1.3G RHCP 150MM
9. Battery Strap 20*300mm*2
1. Frame- 9Inch Carbon Fiber Frame
2. Stack-FC BL F405 ESC F60 Blheli-S 60A -6S
3. DroView 5.8G Reaper Extrme 2.5W 40CH VTX /1.3G 1.6W VTX
4. DroView 1/3 CMOS 1500TVL Camera
5. DroView 3110 1100KV MOTOR
6. HQProp 9 Inch 3-blade PC Props
7.Happymodel 915MHz RX ELRS
8.VTX Antenna 5.8G/1.3G RHCP 150MM
9. Battery Strap 20*300mm*2
10Inch Night Vision FPV Racing Drones Products Description
1. Frame-DroView 10Inch Carbon Fiber Frame
2. Stack-F405 MK2 V2 F55 Blheli-S 55A -6S
3. DroView 5.8G Reaper Extrme 2.5W 40CH VTX /1.3G 1.6W VTX
4. DroView 1/3 CMOS 1500TVL Camera
5. DroView 3115 700KV MOTOR
6. German 1050Prop (2PAIRS)
7. Happymodel 915MHz RX ELRS
8.VTX Antenna 5.8G/1.3G RHCP 150MM
9. Battery Strap 20*300mm*2
1. Frame-DroView13 Inch Carbon Fiber Frame
2. Stack-F405 Blheli-S 80A -8S
3. DroView15.8G Reaper Extrme 2.5W 40CH VTX /1.3G 1.6W VTX
4. DroView1 1/3 CMOS 1800TVL Camera
5. DroView1 4214 660KV MOTOR
6. German 13 inches (2PAIRS)
7. Happymodel 915MHz RX ELRS
8.VTX Antenna 5.8G/1.3G RHCP 150MM
9. Battery Strap 20*400mm*2
Demountable Arm with Motors, which is for safety shipment and Small Packing Volume
The amrs with motor for DroView FPV Drones are demountable. It only need to install 8PCS Scews when install the FPV Drones. In that case,
we can ship the fpv drones by parts for safety shipment. At the meanwhile, the packing volume is smaller when ship by parts.
In that case, we have help our client save much shipping cost.
we can ship the fpv drones by parts for safety shipment. At the meanwhile, the packing volume is smaller when ship by parts.
In that case, we have help our client save much shipping cost.
MOTOR & PROPELLER
Model: DroView 2807 -KV1300 *4pcs
Motor Weight: 47.6g Motor Dimension:33.9*34mm
Internal Resistance: 58m Configuration: 12N/14P Shaft
Diameter: 5.0mm
Rated Voltage: 3-6S
Peak Current: 45.79A Max
Power: 1153.9W
Max Pull: 2239g *4pcs
Prop: GF7*3.5*3
No-load current:0.8A/12V
silica gel:18#200mm
FC & ESC 4in1 STACK
Model: DroView F405 60A
Stack ESC : F60 Blheli-S 60A -6S 37*42.7mm FC: BL F405 (42688P)37*37mm
Mounting: 30.5*30.5mm
Input: 2-6S Consistent
Current: 60A
BEC: 5V 3A, 10V 2A
Temp Protection: YES
Power Cable: 12AWG, 10cm
Weight: 20.5g
current sensor:YES
motor output:8CH Universal serial port:4CH
CAMERA
ITEM: DroView 1800TVL Camera
Sensor: 1/3.cmos
Resolution: 1800TVL
FOV: 165° Lens: 2.1mm
TV System: NTSC & PAL
Image: 4:3/16:9
WDR: Super WDR Min.
Illumination: 0.0001Lux Denoise:3DNR Video output:CVBS ElectronicShutter:PAL:1/50~100,000;
NTSC:1/60~100,000
Wide voltage:5-40V Operation temperature:-20℃~+60℃
Weight:5.9g Size:19*19*20mm
Option:Night vision or Thermal Imaging Camera
VIDEO TRANSMITTER
Item: Item: DroView 5.8G 2.5W VTX (1.3G 1.6W VTX Instead if 5.8G Chips short) Working Voltage:7-36V
Working Current: ≤450mA (12V/800mW),≤850mA (12V/2500mW) Video Input Impedance:75 Video
Format: NTSC/PAL Antenna interface:MMCX 25mW/13.95dBm 500mW/26.02dBm 1000mW/30.3dBm
2500mW/34.04dBm Output Power:PIT/25/500/1000/2500mW Number of Channels: Standard 40 Channels (A/B/E/F/R)
Image transmission protocol:SmartAudio Mounting Hole:20X20.M2 Dimension: 25*37*6.5mm Working Temp: -10-60℃ Weight: 19g
factory
Working Current: ≤450mA (12V/800mW),≤850mA (12V/2500mW) Video Input Impedance:75 Video
Format: NTSC/PAL Antenna interface:MMCX 25mW/13.95dBm 500mW/26.02dBm 1000mW/30.3dBm
2500mW/34.04dBm Output Power:PIT/25/500/1000/2500mW Number of Channels: Standard 40 Channels (A/B/E/F/R)
Image transmission protocol:SmartAudio Mounting Hole:20X20.M2 Dimension: 25*37*6.5mm Working Temp: -10-60℃ Weight: 19g
factory
FAQ
Q: Are you a factory or a trading company?
A: Professional manufacturer for FPV Drones and Accessories
Q: How many can you make for FPV each month?
A: 20,000 PCS FPV Drone each month
Q: What’s the lead-time for 2000pcs FPV Drones?
A: Around 2-3 weeks, but need to check before order
Q: How many samples do you suggest to order?
A:Extrusion damage may occur during transportation. It is recommended to order more than two samples
Q: What about the after-sale service?
A: Free to change if it doesn’t work.
Q: Can you accept OEM?
A: Yes, we can accept OEM, manufacture according to your requirement.
Q: What are your Delivery terms?
A: We accept EXW, FOB, CFR, CIF. You can choose the one which is most convenient or cost effective for you.
Q: What are your main produced items?
A: FPV Drones, Drone parts, Drone accessories, FPV drones Batteries
Q: What is the payment terms?
A: T/T Bank Transfer, L/C, Western union and Trade Assurance.
